- Page 1 “TiSO-PRODUCTION” LTD WAIST-HIGH TURNSTILE ELECTROMECHANICAL SWING GATE Gate-STE Gate-SGE АUIA.203-07 АUIA.203-08 OPERATION MANUAL Rev.1.2 UKRAINE 2024...
-
Page 2: Table Of Contents
Annex C.1. Wiring diagram of the Swing Gate-STE / Gate-SGE type turnstile rev.3.1 ..........24 Annex C.2. Wiring diagram of the Swing Gate-STE / Gate-SGE type turnstile rev.3.1, ІР54 (optional) ....25 Annex D.1 Wiring diagram of the turnstile connection to access control system (ACS) ..........26 Annex D.2 Control panel and connection diagram AUIA.111.22 ................ -
Page 3: Introduction
Operation Manual 3 INTRODUCTION This Operation Manual (hereinafter referred to as OM) covers nonservo waist-high turnstile of swing gate type with electromagnetic lock (hereinafter referred to as the " turnstile "). The Operation Manual contains information about design, specifications, installation for proper operation and maintenance of the turnstile. -
Page 4: Warnings To The Customer
Operation Manual 4 WARNINGS TO THE CUSTOMER ON SAFE OPERATION OF THE TURNSTILE These warnings are designed for ensuring of safety during operation of the turnstile to prevent violation of safety characteristics by improper installation or operation. These warnings are aimed at drawing attention of the customer to safety problems. GENERAL WARNINGS Safety measures and requirements specified in this in this OM must be observed: –turnstile must be connected to ground loop prior to operation;... -
Page 5: Description And Operation
Table 1 - The gate dimensions Angle Type of execution Tubular leaf АUIА of leaf Gate dimensions Model width weight** rotation Т3.KВН.SL Т3.KВН.SP 1000х225х800-1240 585-1025 «Gate-STE» 203-08 Т3.KВН.PL Т3.KВН.PP 1000х225х815/1065* 600/850* Т3.KВН.KL Т3.KВН.KP 90° Т3.KВC.SL Т3.KВC.SP «Gate-SGE» 203-07 Т3.KВC.PL Т3.KВC.PP 1000х225х815/1065*... -
Page 6: Specification
Operation Manual 6 1.1.3. The operation condition parameters according to GOST 15150-69 for climatic modification specified in Table 2. Table 2 - For climatic category NF4 Operation conditions Parameter value Ambient temperature + 1 to + 40 °С Relative humidity 80 % at 20 ºС... -
Page 7: Configuration And Scope Of Delivery
7 - Screws for adjusting the passage width; 4 –Glass leaf or Stainless steel tubular leaf; 8 - Glass holder or place for leaf fixation. – Design of the single turnstile “Gate-STE” and “Gate-SGE” Fig. 2 1.3.2 Turnstile Scope of Delivery The turnstile is delivered by one package. -
Page 8: Design And Operation
Operation Manual 8 1.4 Design and operation 1.4.1 General appearance of the turnstile 1.4.1.1. The swing gate consists of base with frame assembly 1. On top of the frame 1 is installed housing 2 with a glass leaf or stainless steel tubular leaf 4. 1.4.1.2. - Page 9 Operation Manual 9 1.4.1.3 In the bottom part of the frame assembly there is a control unit 6,in upper part there is a mechanism of gate rotation 5 (fig.4-5), that provide rotation of leaf in one direction at angle of 90° and leaf return to its initial position by spring after each passage through the gate.
-
Page 10: Instrumentation, Tools And Accessories
Operation Manual 10 1.4.2.2 Turnstile operating modes (table 4): SINGLE ACCESS – access to be opened in one direction; FREE ACCESS IN ONE DIRECTION –access is always opened; Switching of the turnstile operating modes is performed either by control panel or as part of automated access control system (by means of cards, badges etc.). -
Page 11: Description And Operation Of Controllers As A Component Of The Turnstile
Operation Manual 11 builder's level 1.6 Description and operation of controllers as a component of the turnstile 1.6.1 Description and operation of the turnstile controller РСВ.705.002 The controller is designed for acquisition of commands from external control devices (control panel, access control system etc.) and generation of control signals for swing gate mechanism. - Page 12 Operation Manual 12 1.6.2. Description of jumper configuration J1-J6 The position of the turnstile-gate leaf is fixed by an induction position sensor. If the sensor output is active the leaf closed; If the sensor output isn’t active the leaf opened;...
-
Page 13: Intended Use
Operation Manual 13 2 INTENDED USE 2.1 Operation restrictions 2.1.1 The turnstile must be used in the environment specified in p. 1.1.5 of this document subject to the specifications listed in section 1.2. IT IS FORBIDDEN: 1) TO MISUSE THE TURNSTILE (See section 1 "DESCRIPTION AND OPERATION");... - Page 14 Operation Manual 14 WARNING: When the turnstile damages are detected or in case of shortage of delivery, installation work to be stopped and the turnstile supplier to be referred to. 3) Make sure that the turnstile installation area is ready as follows: •...
- Page 15 Operation Manual 15 10) The turnstile to be installed upright at the prepared location (Fig.11). 1 - Cables to be pulled through available access holes in the turnstile post bottom end part by tilting the gate frame assembly; Fixation holes at the turnstile bottom plate to be aligned with prepared surface holes;...
- Page 16 Operation Manual 16 11) Turnstile connection: а) Power supply cable ~220 V to be connected. - Phase (L) to be connected to the circuit breaker; - Neutral (N) to be connected to terminal ~220V (N); - Earth (РЕ) to be connected to earthing terminal (РЕ).
-
Page 17: Preparation For Use
Operation Manual 17 2.3 Preparation for use 2.3.1 Commission guidelines Prior to the turnstile energization 1) make sure of proper connection and good condition of all connecting cables; 2) clear the turnstile’s leaf rotation area from foreign particles. Rotation of leaf is locked when mains cable of power supply unit is connected to the network. -
Page 18: Maintenance
Operation Manual 18 3 MAINTENANCE 3.1 General guidelines 3.1.1 Commissioning and subsequent maintenance of the turnstile to be performed only by the staff to be in charge of the turnstile. 3.1.2 The turnstile to be serviced only by the staff having the relevant electrical safety qualification level according to the national requirements. -
Page 19: Routine Maintenance
Operation Manual 19 3.3.3 Periodic maintenance is performed at least twice a year and includes as follows: – visual inspection of the turnstile's body, control mechanism and other components for absence of corrosion, warps and other mechanical defects and pollutions; –... -
Page 20: Transportation And Storage
Operation Manual 20 5 TRANSPORTATION AND STORAGE 5.1 Turnstile storage It is forbidden to subject the turnstile to jerks and impacts during storage. Transportation trolleys to be used for handling of the turnstile. In storage facilities there should not be aggressive gases and vapours causing metal corrosion. -
Page 21: Annex А.1. Overall And Installation Dimensions Of The "Gate-Ste" Type Turnstile
Operation Manual 21 Annex А.1. Overall and installation dimensions of the “Gate-STE” type turnstile... -
Page 22: Annex А.2. Overall And Installation Dimensions Of The "Gate-Sge" Type Turnstile
Operation Manual 22 Annex А.2. Overall and installation dimensions of the “Gate-SGE” type turnstile... -
Page 23: Annex B Control Desk And Connection Diagram Auia.111.22
Operation Manual 23 Annex B Control desk and connection diagram AUIA.111.22 1 – control panel housing; 2 – front face; 3, 5 – access direction LED displays; 4 – "SINGLE ACCESS" mode control button; 6 – "FREE ACCESS" mode switch; 7 –... -
Page 24: Annex C.1. Wiring Diagram Of The Swing Gate-Ste / Gate-Sge Type Turnstile Rev.3.1
Annex C.1. Wiring diagram of the Swing Gate-STE / Gate-SGE type turnstile rev.3.1... -
Page 25: Annex C.2. Wiring Diagram Of The Swing Gate-Ste / Gate-Sge Type Turnstile Rev.3.1, Ір54 (Optional)
Annex C.2. Wiring diagram of the Swing Gate-STE / Gate-SGE type turnstile rev.3.1, ІР54 (optional) -
Page 26: Annex D.1 Wiring Diagram Of The Turnstile Connection To Access Control System (Acs)
Annex D.1 Wiring diagram of the turnstile connection to access control system (ACS) Annex D.2 Control panel and connection diagram AUIA.111.22... -
Page 27: Annex D.3 Wiring Diagram Of One Turnstile Connection To Fire Alarm System (Fas)
Annex D.3 Wiring diagram of one turnstile connection to fire alarm system (FAS) Annex D.4 Wiring diagram of two turnstiles connection to fire alarm system (FAS) (for exit) - Page 28 Manufacturer: LLC TiSO-PRODUCTION 14, Promyslova Street, Kyiv, 02088, Ukraine Phone: +38 (044) 291-21-11 Tel./fax: +38 (044) 291-21-02 E-mail: sales@tiso.global www.tiso.global SERVICE CENTER e-mail: service1@tiso.global Our equipment meets the requirements of European standards: EN ISO 12100:2010, EN ISO 14118:2018, EN 60204-1:2018,...
