Welding torch holder
The item described in the following is part of the machine´s scope of delivery.
Item
Symbol Description
1
2
3
4
•
Use the mounting screws to screw the torch holder onto the crossmember of the transport handle.
•
Insert the welding torch into the welding torch holder as shown.
099-005261-EW501
11.04.2012
0
Crossmember of the transport handle
Torch holder
Fan-type lock washers
Fixing screws (x 4)
Design and function
NOTE
Figure 5-12
MIG/MAG welding
35
