Machine description – quick overview
Front view
Item Symbol Description
1
2
3 VRD
0
4
l
5
6
7
8
9
10
11
16
0
Carrying handle
Ready for operation signal light
Signal light on when the machine is switched on and ready for operation
VRD open circuit voltage reducing device (VRD machine version)
The VRD signal light is illuminated, when the voltage reducing device is operating
without fault and the output voltage is reduced to a value specified in the relevant
standard (see technical data).
Main switch, machine on/off
Cooling air inlet
Machine feet
Connection socket, "+" welding current
• MIG/MAG welding:
• MIG/MAG cored wire welding:
• MMA welding:
"-" welding current connection socket
• MIG/MAG welding:
• MMA welding:
Machine control
See Machine control – operating elements chapter
Protective cap (see Sect. "Protective cap")
Torch holder
welding current connection for the welding torch
workpiece connection
workpiece connection
Workpiece connection
electrode holder connection
