Design and function
MIG/MAG welding
5.9.3

MIG/MAG functional sequences / operating modes

Welding parameters such as gas pre-flows wire burn-back etc. are pre-set with optimal
values for numerous applications. These values can, however, be changed with the
PC300.NET software as required.
5.9.3.1

Explanation of signs and functions

Symbol Meaning
Press torch trigger
Release torch trigger
Tap torch trigger (press briefly and release)
Shielding gas flowing
Welding output
I
Wire electrode is being conveyed
Wire creep
Wire burn-back
Gas pre-flows
Gas post-flows
Non-latched
Latched
Time
t
PSTART Ignition program
Main program
PA
End program
PEND
32
NOTE
