Operation
16
When the meter is powered by the batteries, it switches itself off
automatically after an adjustable interval to save the batteries (see
section Automatic switch-off function, page 31).
4.4

Navigation

4.4.1

Operating modes

The meter has the following operating modes:
Operating mode
Measuring
Calibration
Setting
4.4.2

Measuring mode (measured value display)

The following functions are available in the measuring mode (measured value
display):
• Change the display in the selected measuring window (e. g. pH <-> mV) by
pressing <M>
• To open the measurement settings, press <M__> (long pressure).
• To open the system settings, press <ENTER__> (long pressure).
4.4.3

Setting mode

The following functions are available in the setting mode:
• To change the current setting, press <><>.
• Confirm the setting with <ENTER>.
The next setting is displayed.
The settings are stored.
When the last setting is confirmed, the setting menu is auto-
matically quit.
• Press <M> to exit the setting mode.
Description
The measurement data of the connected sensor are
shown in the measured value display
The course of a calibration with calibration informa-
tion, functions and settings is displayed
A setting is displayed.
