Introduction
1.2.1 Article number
C
D
E
F
G
H
Power Supply 2
A
B
C
G
N
Manufacturing modification options
0
1
Service panel options
A00
A01
Slot 1 options
B00
B01
B02
B03
B04
B05
B06
B10
4
Option
HI voltage (88-300 VDC/86-264 VAC) with screw terminal
24 VDC, plug terminal
48 VDC, plug terminal
HI voltage (88-300 VDC/86-264 VAC) with plug terminal
12 VDC, screw terminal
12 VDC, plug terminal
Option
24 VDC
48 VDC
HI voltage (88-300 VDC/86-264 VAC)
12 VDC
No power supply module
Option
None
Conformal coated
Option
LED panel mounted on the front (connector side)
LED panel mounted on the back (heatsink side)
Option
RUGGEDCOM RMM2931-4 (Blank Module)
RUGGEDCOM RMM2973-4RJ45 ( 4 x RJ45, 10/100/1000 BASE-TX)
RUGGEDCOM RMM2973-4FC (4 x FastConnect (RJ45), 10/100/1000 BASE-TX)
RUGGEDCOM RMM2973-4POE (4 x RJ45 supporting Power-over-Ethernet (POE, IEEE
802.3at), 10/100/1000 BASE-TX)
RUGGEDCOM RMM2973-4PFC (4 x FastConnect (RJ45) supporting Power-over-
Ethernet (POE, IEEE 802.3at), 10/100/1000 BASE-TX)
RUGGEDCOM RMM2942-4LC2 (4 x 100MBit/s LC-interface, Optical: 100BASE-FX,
Multi Mode fiber optic up to 2 kilometer, 1310nm)
RUGGEDCOM RMM2972-4SFP (4 x SFP-slot, Supporting 100BASE-FX, 1000BASE-X
SFPs, SFPs are not included)
RUGGEDCOM RMM2973M-4RJ45 (4x RJ45 with MACsec, 10/100/1000 BASE-TX)
Description
Description
Description
Description
Description
