Technical specifications
5.3 PoE output specifications
Internal fuse
Power supply
5.3

PoE output specifications

The RUGGEDCOM RST2228P adheres to the following power output and IEEE 802.3
specifications depending on the input voltage supplied to the device.
IEEE standard
54
Voltage rating
12 VDC 85 VAC/VDC
24 VDC 125 VAC/VDC
48 VDC 125 VAC/VDC
HI AC/DC 400 VDC/ 500
VAC
Input
802.3af 45 to 57 VDC
(Type 1)
802.3at 51 to 57 VDC
(Type 2)
Ampere Fuse type
rating
12 A Very fast acting
10 A Very fast acting
5 A Slow blow
3.15 A Surge withstand
Power in
Internal Required
fuse rating power supply
(maximum) isolation
12 A 1.5 KVAC
2.2 KVDC
Fuse delay
% of ampere Opening time
rating
100% 4 hours
(minimum)
200% 5 seconds
(maximum)
100% 4 hours
(minimum)
200% 5 seconds
(maximum)
100% 4 hours
(minimum)
200% 1 second
(minimum),
60 seconds
(maximum)
150% 60 minutes
(minimum)
210% 30 minutes
(maximum)
275% 0.75 seconds
(minimum),
80 seconds
(maximum)
400% 0.095 seconds
(minimum),
5 seconds
(maximum)
1000% 0.01 seconds
(minimum),
15 seconds
(maximum)
Power out
Output Per port
(maximum)
44 to 57 VDC 15 W
50 to 57 VDC 30 W
