Video Recording
3
Button
4 Key C1
5 Air Outlet
6 HDMI Interface
7 USB-C Interface
8 USB-A Interface
9 Power button
10 Key C2
11 Shooting Button
12 Right Dial Wheel
13 Right Stick
Press the button to start/end recording videos.
Use the Autel Enterprise App to customize the key function. For
more information, see
For heat dissipation of the remote controller. When using it,
please pay attention to whether there are foreign objects
blocking the air outlet.
Outputs the live view of the remote controller to a supported
display device.
Used for remote controller charging or device debugging.
Connects to an expandable 4G/5G module or external USB
device for data transmission.
Long press for 3s to turn on/off the remote controller.
When the remote controller is on, quickly press the power
button to switch between Screen On and Screen Off.
Use the Autel Enterprise App to customize the key function. For
more information, see
Press the button to take a photo.
Turn the dial wheel to adjust the zoom factor of the camera.
Controls the state of motion of the aircraft. The default stick
mode is Mode 2. In this mode, you can use the stick to control
the translation of the aircraft in four directions:
front/back/left/right. You can set the stick mode in the Autel
Enterprise App. For more information, see
Chapter 6.
Chapter 4 Remote Controller
"6.5.3 RC Settings" in Chapter 6.
"6.5.3 RC Settings" in Chapter 6.
65
"6.5.3 RC Settings" in
