132
Chapter 6 Autel Enterprise App
 The temperature of the measured target should be within 600 ℃ . Over-temperature
measurements can cause burns and damage to the infrared detector.
 Set Thermal Color
After tapping the "
color palette.
 After selection, the images from the thermal camera will be displayed in the color style of the
selected color palette.
 Set Infrared Shooting
Tap the "
" icon to enter the "Camera Settings" interface and perform relevant settings. For
more information, see
 Set Radiometric Measurement Mode
Tap the "
" icon or the "
 High gain mode (-20℃ to 150℃): This mode has higher radiometric measurement accuracy
but a smaller radiometric measurement range compared with the low gain mode.
 Low gain mode (0℃ to 550℃): This mode has a larger radiometric measurement range but
lower radiometric measurement accuracy compared with the high gain mode.
 FFC Calibration
Tap the "
" icon to enable the FFC calibration function.
Note
 The radiometric measurement mode and FFC calibration functions can be used only after
the infrared radiometric measurement function is enabled in the camera settings.
 Adjust the Infrared Zoom Factor
While shooting, tap the "
up. You can drag up or down to zoom in or out on the picture captured by the thermal camera,
so as to flexibly shoot objects at different distances.
Tip
 The thermal camera of DG-L35T Gimbal support up to 16x digital zoom.

"Wide Angle Camera" Interface

On the main interface of the Autel Enterprise App, tap the "
Angle Camera" preview interface, or tap the "
interface or "Thermal Camera" interface, to enter the "Wide Angle Camera" full-screen interface.
" icon, you can scroll up and down in the pop-up drop-down list to select a
"6.8.1 Camera Function
" icon to switch between radiometric measurement modes.
" dynamic icon, and the infrared zoom factor setting window will pop
Area" in this chapter.
" icon in the corner of the "Wide
" icon after entering the "Zoom Camera"
