 Add a Rectangular Area
On the map of the rectangle mission interface, find the center point of the mission to be
executed and tap it to automatically generate a rectangular area. You can adjust the area of the
rectangle by dragging the eight white points at the edges of the rectangle. You can drag the
"cross arrow" in the center of the rectangle to move the rectangle or drag the "curved arrow" on
both sides of the rectangle to rotate the rectangle around the center point.
When adding a rectangular area, the rectangle mission settings interface will pop up on the right
side of the rectangle mission interface.
Tip
 A rectangular area includes two waypoints, that is, the starting point (
( ).
 Set Mission Name
On the rectangle mission settings interface:
 Tap the "Mission Name" edit box and enter the name as required to set the name of a
rectangle mission.
 Set Flight Altitude and Relative Height
In the "Flight Altitude (20-800m)" edit box on the rectangle mission settings interface, directly
enter the flight altitude value or tap the shortcut buttons on the left and right sides to adjust the
value. This way, you set the flight altitude of the rectangle mission.
The setting range of "Relative Height" will automatically be dynamically adjusted according to
the flight altitude setting. In the edit box, directly enter the mission altitude value or tap the
shortcut buttons on the left and right sides to adjust the value. This way, you set the relative
altitude of the rectangle mission.
Tip
 The maximum value for the flight altitude setting will be dynamically adjusted according to
the altitude limit set in the "Flight Control Parameter Setting".
 GSD varies with different flight altitude values.
 Set Flight Speed
In the "Flight Speed" edit box on the rectangle mission settings interface, directly enter the flight
speed value or move the slider below left or right to adjust the value. This way, you set the flight
speed of the rectangle mission.
Tip
 The flight speed setting ranges from 1 to 10 m/s.
Tap this icon, and the aircraft will abort the current
Exit Mission
rectangle mission and automatically return.
Chapter 6 Autel Enterprise App
) and the end point
