CONTAIN-IT Plus Ball Valve Type 546 Pro
7

Upgrade with an actuator

The CONTAIN-IT Plus Ball Valve can be upgraded with the EA11, EA21 and PA21 actuators according to the following description.
Please also follow the respective instructions.
To upgrade the CONTAIN-IT Plus Ball Valve you will need the Adaptor Set 700 238 796. This Adaptor Set includes the following items:
Contents
1 x Adaptor Code 198 204 007
1 x Interface adaptor Code 198 803 156
2 x Reducing bush Code 198 803 145
Procedure
1. Make sure that the red hand lever is in parallel position to the
pipe system.
2. Loosen the nuts.
3. Remove the hand lever.
4. Plug the adaptor into the actuator.
20
