Operating Instructions
9

Spare parts list

9.1

Stem

Dimension Ball valve
d20/50 – d32/50
d40/75 – d63/110
9.2

PE-connecting adaptor

Dimension Ball valve
d20/50 – d25/50
d32/63
d40/75 – d63/110
9.3

Union end/union bush

Dimension Ball valve
d20/50 – d25/50
d32/63
d40/75 – d63/110
9.4

Ball Valve Type 546 Pro, central part

9.4.1 EPDM sealing set
Dimension Ball valve
d20/50
d25/50
d32/63
d40/75
d50/90
d63/110
9.4.2 FPM sealing set
Dimension Ball valve
d20/50
d25/50
d32/63
d40/75
d50/90
d63/110
Code
748 410 103
749 410 103
748 410 027
749 410 027
Code
748 410 119
749 410 119
748 410 123
749 410 123
748 410 254
749 410 254
Code
748 410 111
749 410 111
748 410 249
749 410 249
748 410 258
749 410 258
Code
161 486 400
161 486 401
161 486 402
161 486 403
161 486 404
161 486 405
Code
161 486 410
161 486 411
161 486 412
161 486 413
161 486 414
161 486 415
Quantity
2
2
2
2
Quantity
2
2
2
2
2
2
Quantity
2
2
2
2
3 (d63=4)
3 (d63=4)
Description
Sealing set EPDM consisting of:
- 2 backing seals
- 1 body seal
- 2 face seals
- 2 stem seals
Description
Sealing set FPM consisting of:
- 2 backing seals
- 1 body seal
- 2 face seals
- 2 stem seals
CONTAIN-IT Plus Ball Valve Type 546 Pro
Dimension
3.54mm x 29.75mm
3.54mm x 29.75mm
3.54mm x 37.69mm
3.54mm x 37.69mm
Dimension
5.34mm x 71.39mm
5.34mm x 71.39mm
5.34mm x 91.44mm
5.34mm x 91.44mm
7.0mm x 108.0mm
7.0mm x 108.0mm
Dimension
5.34mm x 104.37mm
5.34mm x 104.37mm
5.34mm x 123.19mm
5.34mm x 123.19mm
5.34mm x 146.1mm
5.34mm x 146.1mm
Description
O-ring EPDM
O-ring FPM
O-ring EPDM
O-ring FPM
Description
O-ring EPDM
O-ring FPM
O-ring EPDM
O-ring FPM
O-ring EPDM
O-ring FPM
Description
O-ring EPDM
O-ring FPM
O-ring EPDM
O-ring FPM
O-ring EPDM
O-ring FPM
23
