Upgrade With An Actuator - GF CONTAIN-IT Plus Instruction Manual

Instruction Manual
8

Upgrade with an actuator

The CONTAIN-IT Plus Ball Valve can be upgraded with the EA11, EA21 and PA21
actuators according to the following description. Please also follow the respective
instructions.
To upgrade the CONTAIN-IT Plus Ball Valve you will need the Adaptor Set 700 238
796. This Adaptor Set includes the following items:
- 1 x Adaptor Code 198 204 007
- 1 x Interface adaptor Code 198 803 156
- 2 x Reducing bush Code 198 803 145
Upgrades with other actuators on request.
1. Make sure that the red hand lever is
in parallel position to the pipe system.
2. Loosen the nuts.
3. Remove the hand lever.
4. Plug the adaptor into the actuator.
42
Upgrade with an actuator
Fig. 14
Fig. 15
Fig. 16
