Summary of Contents for Converters.TV 15108
- Page 1 DVI Digital Video Scaler #15108 Operation Manual...
-
Page 2: System Requirements
Introduction The Digital Video Scaler is designed to do scaling and source-switching from CV, SV, PC and DVI input signals, to DVI output port. The external audio input signals can be switched and sent to the L/R output port correspondingly with the video source selection. -
Page 3: Operation Controls And Functions
Operation Controls and Functions Front Panel POWER & LED: Press this button to switch ON or set the device to standby mode. Once the device is connected with power supply the LED will illuminate and the device will switch to ON automatically. This IR window receives only the IR signal from the remote control included in the package. -
Page 4: Remote Control
PC: Connect with PC/NB source equipment for video signal input with D-Sub 15pin cable. CV + L/R: Connect to source equipment such as video/DVD player for both video and audio signal sending. SV + L/R: Connect to source equipment such as video/DVD player for both S-Video and audio signal sending. - Page 5 Baud Rate: 9600bps Data bit: 8 bits Parity: None Flow Control: None Stop Bit: 1 RS232 Commands Command Description Content S SOURCE 1~4 Select input source DVI(1) / VIDEO(2) / SVIDEO(3)/ PC(4) R SOURCE Inquire input source S OUTPUT 0~25 Select output timing Native(0)/ 640*480(1)/ 800*600(2)/ 1024*768(3)/ 1280*768(4)/...
- Page 6 S NR 0~3 Noise reduction OFF(0) / LOW (1) / setting MIDDLE(2) / HIGH(3) R NR Inquire noise reduction setting S AUDIODELAY Audio delay setting OFF(0) / 40ms (1) / 110ms(2) / 150ms(3) R AUDIODELAY Inquire audio delay setting S AUDIOMUTE Audio mute setting ON(0) / MUTE(1) R AUDIOMUTE...
-
Page 7: Auto Setup
1920x1200 60 720X480P 60 1280X720P 60 1920X1080I 60 1920X1080P 60 720X576P 50 1280X720P 50 1920X1080I 50 1920X1080P 50 OVER SCAN SIZE (VIDEO mode only) FULL BEST FIT PAN SCAN LETTER BOX UNDER 2 UNDER 1 MODE INFO INFO PC(PC mode only) AUTO SETUP H_POSITION 0~60 (30) - Page 8 (512) R OFFSET 0~1023 (512) G OFFSET 0~1023 (512) B OFFSET 0~1023 (512) CONTRAST 0~60 (30) 0~60 (30) 0~60 (30) 0~60 (30) 0~30 (0) MIDDLE HIGH VOLUME 0~100 AUDIO DELAY (L/R output only) 40mS 110mS 150mS SOUND MUTE FACTORY RESET SETUP KEY LOCK POWER SAVE...
- Page 9 Specifications Video Bandwidth 165MHz Input Port 1 x Composite, 1 x S-Video, ,1 x VGA, 1 x DVI, 1 x L/R, 1 x LR, 1 x USB (service only), 1 x RS-232 (Control Only) Output Port 1 x DVI, 1 x L/R Supports Input Resolution Up to WUXGA &...
- Page 10 @60Hz WSXGA1680*1050 RB √ √ @60Hz 1920*1080 @60Hz √ √ 1920*1200 RB @60Hz √ √ 480I/576I √ 480P/576P √ 720P(@50/60Hz) √ 1080I(@50/60Hz) √ 1080P(@24/30/50/60Hz) √ DVI/HDMI output Resolution Native 640*480@60Hz 800*600@60Hz 1024*768@60Hz 1360*768@60Hz 1280*720@60Hz 1280*800@60Hz 1280*1024@60Hz 1440*900@60Hz 1400*1050@60Hz 1680*1050@60Hz 1600*1200@60Hz 1920*1080@60Hz 1920*1200@60Hz 480P...
-
Page 11: Connection Diagram
Connection Diagram...
