- Page 1 HDMI/VGA to HDMI 6G Scaler # 15465 Operation Manual...
- Page 2 Introduction This is a compact yet versatile 4K UHD HDMI and PC/HD to HDMI Scaler. It accepts a wide range of resolutions from 480i up to 1080p/WUXGA for PC/HD and up to 4K@60Hz (4:4:4) for HDMI with the ability to scale the output to a selectable resolution up to 4K@60Hz (4:4:4) with simultaneous de-embedded, digital optical and analog audio output.
- Page 3 Applications • Home Theater with 4K@60Hz HDMI media player and VGA home PC with output to a 4K@60Hz TV • Boardroom presenter connection point with auto-switching to new presenters and output to a large 4K display • Lecture Hall, Showroom or Classroom signal display •...
- Page 4 Bitstream formats will be muted. MENU: Press to enter the OSD menu, or to back out from menu items. Note: Pressing “MENU” and “+” together will reset the output resolution to XGA (1024x768@60Hz). Pressing “Menu” and “-” together will reset the output resolution to 720p@60Hz. -/+: Press to move up and down or adjust selections within menus.
- Page 5 OSD Menu Main Menu Sub Menu Parameters Default PICTURE CONTRAST 0~100 BRIGHTNESS 0~100 Exit FINETUNE 0~100 [HDMI/YPbPr SATURATION 0~100 source only] SHARPNESS 0~100 MIDDLE HIGH EXIT FINETUNE PHASE 0~100 [PC source CLOCK 0~100 only] H-POSITION 0~100 V-POSITION 0~100 EXIT COLOR 0~100 GREEN 0~100...
- Page 6 1680×1050@60 1600×1200@60 1920×1200@60 (RB) 480P@60 576P@50 720P@50 720P@60 1080P@50 1080P@60 4K2K@24 4K2K@25 4K2K@30 4K2K@50 4K2K@60 4K2K@50 (4:2:0) 4K2K@60 (4:2:0) NATIVE UHD BYPASS BYPASS SCALER SCALER SIZE* FULL BEST FIT OVER SCAN UNDER SCAN LETTER BOX PAN SCAN BEST FIT EXIT AUDIO HDMI INPUT AUTOMATIC AUTOMATIC...
- Page 7 [Analog audio only] EXIT TIMER 5~100 DISPLAY INFO INFO EXIT EDID MANAGE EDID COPY DEF, 1080P DEF, 1080P [HDMI source DEF, 4K2K (6G) only] DEF, 4K2K DEF, 4K2K (3G) OUTPUT EXIT ADVANCED AUTO SYNC FAST [≈ 10 sec.] SLOW [≈ 120 sec.] AUTO INPUT OFF AUTO SWITCH...
- Page 8 resolution by pressing “Enter”. If “Enter” is not pressed within 30 seconds the output will return to the previous resolution automatically. Supported Resolutions PC Resolution (Hz) HDMI HDMI Input Input Output 640×480@60/72/75/85 800×600@56/60/72/75/85 60Hz only 1024×768@60/70/75/85 1280×1024@60/75/85 1360×768@60 1280×800@60 1280×1024@60 1440×900@60 1400×1050@60 1600×1200@60...
- Page 9 Scaled Resolutions Input Resolution Output Resolution UHD BYPASS SCALER BYPASS Bypass Scaler Bypass Scaler Path Path Path Path Non-4K Timing Any Timing 4K but not 24Hz 4K@24Hz 4K but not 25Hz 4K@25Hz 4K but not 30Hz 4K@30Hz 4K but not 50Hz 4K@50Hz Note 4K but not 60Hz...
- Page 10 Sampling Rates (kHz) HDMI OPTICAL 44.1 88.2 176.4 Input Output Frequency THD+ Frequency Level Level Crosstalk Range Response Digital Audio Digital Audio 0 dB 1 kHz 0 dB ~ -1 < 0.01 ± 1 dB > 80 dB < -80 dB Analog Audio Digital Audio 1Vrms...
- Page 11 Connection Diagram...
- Page 12 Specifications 600MHz/18Gbps Video Bandwidth Input Ports 1×HDMI, 1×VGA [15-pin D-sub], 1×Optical Audio, 1×3.5mm Audio Output Ports 1×HDMI, 1×Optical Audio, 1×3.5mm Audio Supported Resolutions 408i@60Hz - 4K@60Hz (4:4:4, 8-bit) VGA@60Hz - WUXGA@60Hz (RB) Cable Length 10 m (1080p@60Hz, 12-bit) 5 m (4K@60Hz, 4:4:4, 8-bit) Power Supply 5V/2.6A DC (US/EU standards, CE/FCC/UL certified)
