Technical Specifications - Omcan IC-IT-0003 Instruction Manual

Safety and Warranty
WARNING:
The packaging components (cardboard, polyethylene, and others) are classified as normal solid urban waste
and can therefore be disposed of without difficulty.
In any case, for suitable recycling, we suggest disposing of the products separately (differentiated
waste) according to the current norms.
DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

Technical Specifications

Model
Capacity
RPM
Power
Electrical
Dimensions
Packaging Dimensions
Weight
Packaging Weight
Item Number
Installation
POSITIONING THE MACHINE
The surface on which the machine is to be placed must take into account the support size indicated in Tab. 1,
and therefore be big enough; it must be perfectly level, dry, smooth, sturdy and stable. In addition, the machine
must be placed in a room with max. 75% humidity, non-saline and a temperature between +5°C and +35°C; in
any case, in environments that do not involve dysfunctions of the same.
SINGLE-PHASE ELECTRICAL CONNECTION
The machine is equipped with a power cord 3 x 18 AWG; length 1.6 m and a NEMA 5-15P plug. Connect
the machine 120 Volt 60 Hz, interposing a 10A, D I = 0.03A differential—magnetothermic switch. Make sure
IC-IT-0003
3 L / 3.2 QT
800 RPM
150 W
110-120V / 60Hz / 1
11.2" x 8.1" x 19.3" / 284 x 206 x 490mm
16.1" x 11" x 22" / 409 x 279 x 559mm
11.5 lbs. / 5.2 kgs.
17.6 lbs. / 8 kgs.
47084
