Technical Specifications - Omcan IC-CN-0129S Instruction Manual

Model
Power
Electrical
Bin Capacity
Production Per Day
Ice Shape
Max Ambient
Temperature
Condenser Unit
Refrigerant
Weight
Packaging Weight
Dimensions
Packaging
Dimensions
Item Number
The ice machine should be installed in a proper location meeting the following conditions:
• Indoor, not more than 2,000 meters above sea level.
• Ambient temperature cannot exceed 32°C.
• Power supply: the rated voltage indicated on the machine nameplate ±6%.
• Water source: potable water, with water pressure from 1.3 Bar to 5.5 Bar; water temperature: 5-35°C.
• The ice machine should be kept away from heat sources, and should be strictly forbidden to use at
extremely high temperature or low temperature environment, and should avoid direct sunlight.
• There should be sufficient ventilation space around the ice machine and keep good ventilation; the distance
from the ice maker to the wall should be no less than 30 cm for the front, 15cm for the sides, and 20 cm for
the rear.
• The ice machine must be placed on a floor sufficient to support its weight.
• Socket for the ice maker must be reliably grounded and with leakage protection.
• Proper floor drainage must be provided near the installation location of the ice machine.
INSTALLATION STEPS
1. Check if the ice machine is in good condition and the accessories are complete; check the machine model
and the machine nameplate.

Technical Specifications

IC-CN-0129S
446 W
40 lbs. / 18 kgs.
120 lbs. / 55 kgs. 210 lbs. / 95 kgs.
99.2 lbs. / 45 kgs. 127.9 lbs. / 58 kgs.
110.2 lbs. / 50 kgs. 145.5 lbs. / 66 kgs.
19.7" x 23.2" x 35.4" 26" x 27" x 38.2"
500 x 590 x 900mm 660 x 685 x 970mm
22.8" x 26.4" x 32.9" 30.7" x 29.3" x 35.4"
580 x 670 x 835mm 780 x 745 x 900mm
47483
IC-CN-0219S IC-CN-0329
526 W
115V / 60Hz / 1
80 lbs. / 36 kgs. 275 lbs. / 125 kgs.
350 lbs. / 160 kgs.
Cube
5 - 40°C | 41 - 104°F
Air
R290
187.4 lbs. / 85 kgs.
207.3 lbs. / 94 kgs.
22" x 32.7" x 67.6"
560 x 830 x 1718mm
Unit: 25.8" x 29.5" x 24.4"
655 x 750 x 620mm
Bin: 25.4" x 35" x 41.5"
645 x 890 x 1055mm
47484
9
IC-CN-0529
790 W 1113 W
375 lbs. / 170 kgs.
500 lbs. / 225 kgs.
Half or Full cube
242.5 lbs. / 110 kgs.
264.6 lbs. / 120 kgs.
29.9" x 32.7" x 67.6"
760 x 830 x 1718mm
Unit: 33" x 29.5" x 24"
845 x 750 x 620mm
Bin: 33.4" x 35" x 41.5"
850 x 890 x 1055mm
47485 46452
Installation
