Technical Specifications - Omcan IC-CN-0040 Instruction Manual

Model
Production
Capacity
Electrical
Current
Refrigerant
Weight
Packaging Weight
Dimensions
Packaging Dimensions
Item #
Note: Installation should be performed by a trained Service Technician. For proper operation of the ice
machine, the following installation guidelines must be followed. Failure to do so may result in loss of production
capability, premature part failure, and may void any warranties.
AMBIENT OPERATING TEMPERATURES
Minimum Operating Temperature: 50°F (10°C).
Maximum Operating Temperature: 100°F (38°C).
Note: The unit is not designed for outdoor use.
INCOMING WATER SUPPLY
Minimum incoming water temperature: 40°F (5°C).
Maximum incoming water temperature: 90°F (32°C).
Minimum incoming water pressure: 15 psig.
Maximum incoming water pressure: 80 psig.
Note: If water pressure exceeds 80 psig, a water pressure regulator must be installed.
DRAINS
Route bin drain, purge drain and water condenser drain must be individually connected to a floor drain. The
use of condensation pumps for draining water on equipment should not produce over 200 lbs./day. Omcan
assumes no responsibility for improperly installed equipment.

Technical Specifications

IC-CN-0040
264.5 lbs./day (120 kg./day)
88.25 lbs. / 40 kg.
115V / 60Hz / 1
R404a, 680g
143.25 lbs. / 65 kg.
161 lbs. / 73 kg.
24" x 24.25" x 38.75" / 609.6 x 616 x 984.3mm
26.25" x 26.5" x 39.5" / 666.8 x 673.1 x 1003.3mm
5
9.2A
27936
Installation
