Page 1: Ice Makers
Ice Makers Models IC-CN-0016 Instruction Manual Revised - 1/8/2015 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: sales@omcan.com www.omcan.com... -
Page 2: Table Of Contents
Table of Contents Model IC-CN-0016 Section Page General Information --------------------------------------------------------------------------- 3 - 4 Safety & Warranty ------------------------------------------------------------------------------ 4 - 6 Technical Specifications -------------------------------------------------------------------------- 6 Installation -------------------------------------------------------------------------------------- 7 - 11 Operation -------------------------------------------------------------------------------------- 11 - 14 Maintenance --------------------------------------------------------------------------------- 15 - 18 Troubleshooting... -
Page 3: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 4: Safety & Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. - Page 5 1 YEAR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule a drop off to either an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the equipment. Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures not...
-
Page 6: Technical Specifications
In any case, for suitable recycling, we suggest disposing of the products separately (differentiated waste) according to the current norms. DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT! Technical Specifications Model IC-CN-0016 Rated power 115V AC~60Hz Refrigerant R134a, 8.47oz Ice-making rated current 7.5A... -
Page 7: Installation
Installation UNPACKING Excessive Weight Hazard Use two or more people to move and install icemaker. Failure to do so can result in back or other injury. Remove Packaging Materials IMPORTANT: Do not remove any permanent instruction labels or the data label on your ice maker. Remove tape and glue from your ice maker before using. -
Page 8: Leveling The Ice Maker
Installation the ice maker to be pulled forward for servicing if necessary. • Choose a well ventilated area with temperatures above 50ºF and below 90ºF. This unit MUST be installed in an area protected from the elements, such as wind, rain, water spray or drips. •... - Page 9 Installation down ELECTRICAL REQUIREMENTS Before you move your ice maker into its final location, it is important to make sure you have the proper electrical connection: A standard electrical supply (115VAC, 60Hz.), properly grounded in accordance with the National Electrical Code and local codes and ordinances, required. It is recommended that a separate circuit, serving only your ice maker, be provided.
- Page 10 Installation IMPORTANT: 1. All installations must be in accordance with local plumbing code requirements. 2. Make certain that the pipes are not pinched or kinked or damaged during installation. 3. Check for leaks after connection. Tools required: • Open-end wrenches. •...
-
Page 11: Operation
Installation 4. Pour 1 gallon of water into the ice storage bin to check leaks at all drain connections and at the nut of the drain water hole. Tighten any connections or nuts that leak. IMPORTANT: poor drainage will cause a high rate of ice melting in the ice storage bin. INSTALLATION TYPES This ice maker has been designed to be enclosed (as under a cabinet). -
Page 12: Operating Method
Operation 2. Do you clean the ice storage bin? 3. Have the installation instructions been followed, including connecting the machine to water, drain and electricity? 4. Has the machine been leveled? 5. Is the ice maker in a site where the ambient temperature is within 50ºF to 90ºF and the water temperature within 41ºF - 90ºF all year around? 6. - Page 13 Operation HOW THE MACHINE MAKES ICE There are two distinct cycles: freeze and harvest. The freeze cycle happens when water is flow to the evaporator surface. The harvest cycle is when the ice is released and water enters the machine. A complete cycle takes about 20 minutes.
- Page 14 Operation HOW THE MACHINE USES THE WATER The ice maker begins with a fixed charge of water that is contained in the water bin. As the water is flow to the freezing evaporator surface, the part of water that does not contain mineral impurities will freeze and stick to the ice cube molds.
-
Page 15: Maintenance
Maintenance If the icemaker is left unused for a long time, before the next use it must be thoroughly cleaned. Follow carefully any instructions provided for cleaning or use of sanitizing solution. Do not leave any solution inside the icemaker after cleaning. - Page 16 Maintenance CONDENSER CLEANING A dirty or clogged condenser prevents proper airflow, reduces ice making capacity, and causes higher than recommended operating temperatures that may lead to component failure. Have the condenser cleaned at least once every three mouths. 1. Unplug the ice maker or disconnect power. 2.
-
Page 17: Water Distribution Tube Cleaning
Maintenance WATER DISTRIBUTION TUBE CLEANING When you find that the ice cubes are incompletely formed or the output of ice cubes is low, the water distribution tube may be blocked. Set the power switch to OFF. Unscrew the six screws holding the top panel and remove the panel. -
Page 18: Troubleshooting
Maintenance 2. Remove all ice cubes from the storage bin. 3. Remove the screws in the front cover, push forward to remove the front cover. Locate the control box. 4. Prepare a sanitizing solution by mixing 1 oz. household bleach with 1 gallon of warm water. 5. - Page 19 Troubleshooting TROUBLESHOOTING GUIDE Problem Possible Cause Probable Correction The machine doesn’t operate. The ice maker is unplugged. Plug in the ice maker. The fuse is blown. Replace the fuse. Call for service to check for a short circuit in the ice maker.
- Page 20 Troubleshooting Noise during operation. The feet are not leveled and Level and lock the feet. See locked. Leveling the Ice Maker. Certain sounds are normal. See Normal Sounds. The ice maker stops suddenly The electricity is off. Reconnected the power supply while making ice.
-
Page 21: Parts Breakdowns
Parts Breakdown Model IC-CN-0016 37865... -
Page 22: Parts Breakdowns
Parts Breakdown Model IC-CN-0016 37865 Description Position Description Position Description Position Controller Box Storage Bin Water Supply Pipe Left Foot Water Trough Outlet Hose Nut of Water Inlet Pipe Right Foot Water Pump Supporting Pipe Condenser Water Pump Inlet Hose... -
Page 23: Electrical Schematics
Electrical Schematics Model IC-CN-0016 37865... -
Page 24: Notes
Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________... -
Page 25: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 26 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
