Santos Ice Crusher
Model Santos 53
Item 39689
Instruction Manual
Revised - 01/07/2020
Toll Free: 1-800-465-0234
Fax: 905-607-0234
Email: service@omcan.com
www.omcan.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Santos 53 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Omcan Santos 53

Summary of Contents for Omcan Santos 53

  • Page 1 Santos Ice Crusher Model Santos 53 Item 39689 Instruction Manual Revised - 01/07/2020 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...

  • Page 2: Table Of Contents

    Table of Contents Model Santos 53 Section Page General Information --------------------------------------------------------------------------- 3 - 4 Safety and Warranty --------------------------------------------------------------------------- 4 - 6 Technical Specifications -------------------------------------------------------------------------- 7 Operation ----------------------------------------------------------------------------------------- 7 - 8 Maintenance ------------------------------------------------------------------------------------- 8 - 9 Troubleshooting ------------------------------------------------------------------------------- 9 - 11 Instructions Français...

  • Page 3: General Information

    If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents.

  • Page 4: Safety And Warranty

    Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia.
  • Page 5 5. The base must not be immersed in water. 6. Do not use the appliance if the power supply cord is damaged. It must be replaced by either a Omcan approved dealer or a person with similar qualifications to avoid any danger.
  • Page 6 1 YEAR PARTS AND LABOUR BENCH WARRANTY Within the warranty period, contact Omcan Inc. At 1-800-465-0234 to schedule a drop off to either an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the equipment.

  • Page 7: Technical Specifications

    Technical Specifications MAIN TECHNICAL PARAMETERS Model Santos 53 Power 155 W Efficiency 5.3 lbs. / 2.4 kgs. per min Electrical 120V / 60Hz / 1 Base/Casing Dimensions 12” x 8” x 19” / 305 x 203 x 483mm Weight 22 lbs. / 10 kgs.

  • Page 8: Operation

    Operation CHOOSING THE SIZE OF CRUSHED ICE: The appliance does not require any adjustment. The left-hand button (5) is provided to obtain small-sized crushed ice. The right-hand button (4) is provided to obtain big-sized crushed ice. USING THE MANUAL OR AUTOMATIC MODE: Manual mode Prolonged pressing of one of the buttons (4 or 5) starts up the manual mode.

  • Page 9: Troubleshooting

    (15 to 30 seconds) before starting the machine back up. If the problem persists, switch off the power supply to the machine (unplug the power cord from the mains socket) and call in the maintenance service or contact a Omcan approved dealer. SAFE ACCESS TO THE TOOLS: The appliance can only be started up if the cover (1) is closed.
  • Page 10 Troubleshooting The appliance does not start • Check: the mains power supply and the condition of the power cable. • Check that the luminous indicator lamp at the outlet of the crushing unit (9) goes on for approximately ten seconds when the appliance is connected to the mains power supply. •...

  • Page 11: Instructions Français

    6. Ne pas utiliser l’appareil si le cordon d’alimentation est endommagé. Il doit être remplacé soit par un concessionnaire Omcan approuvé ou une personne de qualification similaire afin d’éviter tout danger. 7. L’appareil doit être débranché avant toute intervention sur elle: le nettoyage, les soins, l’entretien général.
  • Page 12 1 AN PIÈCES ET TRAVAIL BANC GARANTIE Dans la période de garantie, contacter Omcan Inc. A 1-800-465-0234 pour planifier une déposer soit un dépôt Omcan de service autorisé dans la zone, ou à un entrepôt de service Omcan de réparer l’équipement.
  • Page 13 En tout cas, pour le recyclage approprié, nous suggérons au rebut des produits séparément (différenciée des déchets) selon les normes actuelles. NE PAS JETER MATÉRIAUX D’EMBALLAGE DANS L’ENVIRONNEMENT! SPÉCIFICATIONS TECHNIQUES PRINCIPAUX PARAMÈTRES TECHNIQUES Modèle Santos 53 Puissance 155 W La production 5.3 lbs. / 2.4 kgs. per min Électrique 120V / 60Hz / 1 Base / boîtier...
  • Page 14 Instructions Français 7. Le bouton de gauche (5) est fourni pour obtenir de petite taille de la glace pilée. 8. Le bouton de droite (4) est fourni pour obtenir de grandes dimensions de la glace pilée. 9. (La glace pilée tombe dans le seau à glace) (fig. E). COMMENT ARRÊTER LA MACHINE: L’appareil est à...
  • Page 15 étranger de l’unité de broyage, puis initialiser l’appareil (maintenez les 2 boutons (4) et (5) pendant 2 secondes). Si le problème persiste, éteignez l’alimentation de la machine (débranchez le cordon d’alimentation de la prise de courant) et appeler le service de maintenance ou contacter un revendeur Omcan approuvé. SECURITE SURCHAUFFE MOTEUR: En cas de surchauffe du moteur, l’appareil arrête automatiquement.
  • Page 16 Soigneusement déterminer la raison de l’arrêt de l’appareil. Dans tous les cas, si le problème persiste, éteignez l’appareil (débrancher la prise du cordon d’alimentation secteur) et faire appel à une personne du service de maintenance ou contacter un revendeur agréé Omcan. L’appareil ne démarre pas •...
  • Page 17 Numéro Numéro de Numéro de modèle du La description d’article modèle fabricant Broyeur à glace 330 lb / 150 kg Par heure 39689 Santos 53 53V1 Capacité 0.2 HP / 130 W 125V cETLus Figure Drawings Fig. A Fig. C...

  • Page 18: Figure Drawings

    Figure Drawings Fig. D Fig. F Fig. E...

  • Page 19: Parts Breakdown

    Parts Breakdown Model Santos 53 39689...
  • Page 20 Parts Breakdown Model Santos 53 39689 Item No. Description Position Item No. Description Position Item No. Description Position Ice Cubes Tank and Cover Assembly AC394 53100 AC397 Gear Motor Front Flange for 53V1 53252 41757 Left Flange for 53V1 53511...

  • Page 21: Electrical Schematics

    Electrical Schematics Model Santos 53 39689...

  • Page 22: Notes
