Summary of Contents for Omcan IC-CN-0089ST
- Page 1 Ice Maker Model IC-CN-0089ST Item 48054 Instruction Manual Revised - 06/18/2024 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com *Water bottle not included.
-
Page 2: Table Of Contents
Table of Contents Model IC-CN-0089ST Section Page Disclaimer ----------------------------------------------------------------------------------------------------- 3 General Information --------------------------------------------------------------------------------- 4 - 5 Safety and Warranty --------------------------------------------------------------------------------- 6 - 8 Technical Specifications ------------------------------------------------------------------------------- 9 Installation --------------------------------------------------------------------------------------------- 9 - 10 Operation ---------------------------------------------------------------------------------------------- 10 - 13 Maintenance ---------------------------------------------------------------------------------------- 13 - 20... -
Page 3: Disclaimer
Disclaimer OMCAN IS NOT RESPONSIBLE FOR ANY DAMAGES DUE TO WATER LEAKS. WARRANTY FOR WATER LEAKS IS VOID IF THE WICKING PAD IS NOT REPLACED EVERY SIX MONTHS, AND IF THE AMBIENT ROOM TEMPERATURE EXCEEDS 75°F AND 55% RELATIVE HUMIDITY, AND THE APPLIANCE DRAIN IS NOT CONNECTED DIRECTLY TO THE FLOOR DRAIN. -
Page 4: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. - Page 5 Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia.
-
Page 6: Safety And Warranty
Safety and Warranty Please pay attention to the following warning labels on the ice maker. This label indicates a hazardous voltage. There is a risk of electric shock. This label indicates a hazardous voltage. There is a risk of electric shock. This label indicates rotating components inside. - Page 7 Safety and Warranty This label indicates a flammable refrigerant “R290” used. There is a risk of fire. WARNING AND SAFETY INSTRUCTION This product cannot be used in outdoor environment. This ice machine is not intended for use by children, and those with physical weakness, slow response, or mental disorders.
- Page 8 1 YEAR PARTS AND LABOUR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized service technician to repair the equipment locally.
-
Page 9: Technical Specifications
Technical Specifications Model IC-CN-0089ST Item Number 48054 Power 350 W Electrical 110-120V / 60Hz / 1 Bin Capacity 33.1 lbs. / 15 kgs. Production per Day 79.4 lbs. / 36 kgs. Ice Shape Cube Max Ambient Temp 24°C / 75°F... -
Page 10: Installation
Installation and the machine nameplate. 2. Clean the ice bin and the food area inside with a sponge soaked in warm water and soda. Then wash and dry it with potable water. 3. Place the ice machine in the operation area; ensure that the machine is placed on a leveled floor. So as to ensure the water flows evenly on the evaporator. -
Page 11: Operation
Operation • The pump is working properly and water is flowing evenly on the evaporator. • The compressor is running normally, the temperature of the evaporator and the ice making water is gradually decreasing. • For air cooled machine, check the fan is running normally, and there is stable air flow in the inlet and outlet of the ice machine. - Page 12 Operation INSTRUCTION OF CONTROL PANEL 1. LED Display: • Self-check: display “ini” code. • Preparing: counting seconds positively. • Ice making: counting seconds positively as the water temperature decreases to 0ºC. Counting seconds down to 0 s after. • Ice harvest: counting seconds positively. •...
-
Page 13: Maintenance
Operation • The ice machine detects that the ambient temperature is too high and will stop for safety protection. • If the water-cooled ice machine detects an abnormality in water supply, it will stop for safety protection. Maintenance Note: maintenance must be done by a qualified professional personal. Warning: before maintenance or manual clean, be sure to cut off the water source and power supply. - Page 14 Ratio of Disinfection Model Ratio of Water Ratio of Scale Remover Powder IC-CN-0089ST 1.5L 11.5g MANUAL CLEANING PROCESS 1. Remove ice cubes from the ice bucket to avoid contamination. 2. Remove the upper and lower fixing screws on the front panel of the ice machine, a total of 4 screws;...
- Page 15 Maintenance 4. Ensure the power is turned off and remove the ice shield. 5. Remove the spray pipe fixing screws (2 pieces) and remove the spray pipe. 6. Remove 2 water pump fixing screws. 7. Unplug the water pump and sensor wiring harness.
- Page 16 Maintenance 8. Unplug the water inlet pipe. 9. Remove the water pipe hose clamp. 10. Remove the spray pipe fixing screws and disassemble the spray pipe.
- Page 17 Maintenance 11. Prepare the cleaning solution specified in the above chart, make sure the cleaning agent is completely dissolved. Soak the water pipe, spray pipe, inner pipe, outer pipe, head, spray pipe fixing seat and screws in the cleaning solution and shake slowly. After 15 minutes, rinse with clean water. 12.
- Page 18 Maintenance 2. Use the solution to repeatedly scrub the spray pipe, ice baffle and water pump base bracket; let it sit for 15 minutes, then rinse with clean water. 3. Use a spray bottle to spray the solution into the inside of the ice tray, and use the solution to repeatedly wipe the sink, ice tray and its plastic parts, both side panels, ice buckets and other sanitary areas;...
- Page 19 Maintenance EXTERIOR CLEANING • Frequently clean the environment around the ice machine to keep it clean. Do not block the vents. • The outer enclosure should be cleaned with a mild detergent and then wiped clean. If necessary, use commercial stainless steel cleaners and polishes. Note: stainless steel may rust without proper maintenance.
-
Page 20: Troubleshooting
Maintenance • Push “clean” button. The ice maker will do auto clean for about 15 minutes. Please do spray cleaning to the evaporator at the mean time to insure a complete clean. When finished, the led display flashes “Clean” slowly again. •... - Page 21 Troubleshooting The display shows E04 high The ambient temperature is too Normal working temperature range temperature / the display shows high. of 24°C. E06 high pressure protection. Condenser or air filter is dirty and Clean the condenser and air filter. blocked.
- Page 22 Troubleshooting ERROR CODES Code Fault Possible Cause Solution Fault free. Ice skating Ice skating board deformation. Replace the ice skating board or reinstall board or ice the ice full switch. Judgment method: visual full switch inspection. fault. The ice full switch is faulty or falls Replace the ice full switch.
- Page 23 Troubleshooting Ice making Water temperature sensor failure. Replace the water temperature sensor, the over time. condensing temperature sensor and the PC PC board failure. board in order, restart the ice machine and Condensation temperature sensor test whether the ice is normal. failure.
- Page 24 Troubleshooting Ice unload over Ice full sensor failure. Replace the ice full switch. Judgment time. method: open the ice shield and start the ice machine. If E01 is not displayed, ice full sensor cannot be released, the fault occurs. Insufficient water supply during ice Check if the inlet battery valve is working making.
- Page 25 Troubleshooting High The fan does not turn (aircooled Check whether the fault comes from fan or Temperature type). PC board. Check if there is voltage output fault. on the fan terminal of the PC board with a multimeter. If not, the fault belongs to the PC board.
- Page 26 Troubleshooting Water shortage Inlet valve failure, or PC board Check if there is voltage output at the output fault. failure. terminal of the inlet valve with a multimeter. If there is output without water, the inlet valve is faulty. If the output terminal has no output, the PC board is faulty.
- Page 27 Troubleshooting Overpressure Electrical failure: the fan does not Check whether the fault comes from fan or fault. turn (air-cooled model). PC board. Check whether there is voltage output on the fan terminal of the PC board with a multimeter. If there is no output, the PC board is faulty.
- Page 28 Troubleshooting Evaporator Water temperature sensor failure. Replace the water temperature sensor. sensor open The wiring is loose or broken. Replace the water temperature sensor. circuit fault. Wiring error. Correct the wiring. Evaporator Water temperature sensor failure. Replace the water temperature sensor. sensor short Wiring error.
-
Page 29: Parts Breakdown
Parts Breakdown Model IC-CN-0089ST 48054... - Page 30 Parts Breakdown Model IC-CN-0089ST 48054 Item No. Description Position Item No. Description Position Item No. Description Position PC Board + Control Panel for AL111 AN290 Left Column for 48054 AN301 Drying Filter for 48054 48054 Foam Box Assembly-Blue Color Front Vent Window Assembly for...
-
Page 31: Electrical Schematics
Electrical Schematics Model IC-CN-0089ST 48054... -
Page 32: Notes
Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________... - Page 33 Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________...
- Page 34 Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________...
-
Page 35: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 36 à plus de 6500 produits provenant du monde entier. Desde 1951 Omcan ha crecido hasta convertirse en un líder en la distribución de equipos y suministros de alimentos en América del Norte industria de servicios. Nuestro éxito en estos años se puede atribuir a nuestro compromiso de fortalecer y desarrollar nuevas relaciones...
