Technical Specifications - Omcan IC-CN-0012 Instruction Manual

MAIN COMPONENTS
1. Condenser
2. Fan motor
2.1. Fan blade
2.2. Fan motor support
3. Multi-connection pipe
4. Hot gas valve coil

Technical Specifications

Capacity 50 lbs./day
Electrical 115V/60Hz/1
Current 3A - 3.6A
Refrigerant R134a
Weight 83.75 lbs.
Dimensions 14.5" × 23.5" × 33.25"
4.1. Hot gas valve body
5. Temperature sensor of
the condenser
6. Drier & Filter
7. Wiring harness
8. Hot gas tube
9. Capillary tube
10. Discharge tube
5
11. Compressor
12. Suction tube
25. Evaporator (Ice Mold)
26. Temperature sensor of the evaporator
32. Control panel
38. Controller box
