- Page 1 Santos Ice Crusher Model Santos 09 Item 44023 Instruction Manual Revised - 01/08/2020 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
-
Page 2: Table Of Contents
Table of Contents Model Santos 09 Section Page General Information --------------------------------------------------------------------------- 3 - 4 Safety and Warranty --------------------------------------------------------------------------- 4 - 6 Technical Specifications -------------------------------------------------------------------------- 6 Operation ----------------------------------------------------------------------------------------- 6 - 8 Maintenance ------------------------------------------------------------------------------------- 8 - 9 Troubleshooting ------------------------------------------------------------------------------------- 9 Figure Drawings... -
Page 3: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 4: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. - Page 5 1 YEAR PARTS AND LABOUR BENCH WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule a drop off to either an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the equipment.
-
Page 6: Technical Specifications
In any case, for suitable recycling, we suggest disposing of the products separately (differentiated waste) according to the current norms. DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT! Technical Specifications Model Santos 09 Electrical 100-120V / 60Hz / 1Ph Power 650W / 0.87 Hp Current 5.4A... -
Page 7: Operation
Operation Note: removing the drawer (1) or lifting up the chute (3) stops the appliance from working (figure 6). For easier cleaning, do not leave food to dry in the drawer or on the grating disc. CHANGING DISC Push the end of the lever (4), pull on the closing key (14) and remove the chute + lever unit to get to the disc (6) (figure 2). -
Page 8: Maintenance
Operation MOTOR OVERLOAD SAFETY FEATURE: Should the motor become blocked (foreign body, object that is too hard, too much pressure with the lever on the products being processed), the On / Off switch (5) automatically trips to the 0 position. Correct the problem and press the On / Off switch (5) (position 1). -
Page 9: Troubleshooting
(3)). THE APPLIANCE STOPS FURTHER TO AN OVERLOAD: See the chapter “motor overload safety feature”. REFERENCE Manufacturer Model Item Number Model Number Description Number Ice Crusher Traditional Ice Shaver with 44023 Santos 09 09V1 Lever 09 cULus... - Page 10 Figure Drawings...
- Page 11 Figure Drawings...
-
Page 12: Parts Breakdown
Parts Breakdown Model Santos 09 44023... - Page 13 Parts Breakdown Model Santos 09 44023 Item No. Description Position Item No. Description Position Item No. Description Position Complete Crushing Disc with Snow Blade AC432 Aluminum Lever for 09V1 09122 AC462 09200S AC485 Ondulated Washer 6202 for 09V1 09340 + Locking Screw for 09V1...
-
Page 14: Electrical Schematics
Electrical Schematics Model Santos 09 44023... -
Page 15: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 16 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
