Meta System META EVOCAN Installation Instructions Manual page 8

OPERATION BY REMOTE CONTROL: Electrical connection suggestions
SIREN
PRE-WIRING
(fi g. 26/27/28/29)
PRE-WIRING
FOR BONNET
PROTECTION
(fi g.14)
DOOR
PROTECTION
BOOT
PROTECTION
DIRECTION
INDICATORS
COLLEGAMENTI AUX
ENGINE
IMMOBILISATION
NEGATIVE
COMMAND
HORN RELAY
Fig. 2
(13)
(11)
(10)
(1)
PURPLE
(9)
GREEN
PURPLE (14)
(20)
LIGHT BLUE
DARK BLUE (23)
BROWN (12)
MOUNT
15A FUSE
(22)
RED
(19)
BLACK
(2)
ORANGE
(21) LIGHT BLUE/GREEN
(24)
(5)
(24)
PINK/BLACK
(8)
PINK
(15)
YELLOW
8
SENSOR FOR
VOLUME
PROTECTION
(RED)
SENSOR FOR
VOLUME
PROTECTION
(BLACK)
POSITIVE
BATTERY (+30)
EARTH
IGNITION KEY
POSITIVE (+15)
DIRECTION
INDICATORS
NEGATIVE OUTPUT CENTRAL
DOORLOCKING OPEN
NEGATIVE OUTPUT CENTRAL
DOORLOCKING CLOSING
CONTROL OF ELECTRIC
WINDOW (M2008 OPT)
POSITIVE COMMAND
AUXILIARY MODULES
POSITIVE ALARM
INPUT
