OPERATION BY REMOTE CONTROL: Installation
The alarm is activated by pressing the ID-Tag B9.5 radio control button, the arming can be signaled by fl ashes of
the turning indicators, an acoustic signal and the LED fl ashing that through an initial speed fl ashing warns of the state of
immunity.
During the fi rst 25 seconds of the immunity time any alarm stimule will be signaled by a short beep.
The alarm system it will be fully operational after 25 sec. since the last alarm stimule detection, if during the immunity time
no stimule will be detected after 25 seconds the alarm system will be fully operative.
The fully operative status will be signaled by the slow fl ashing of the LED.
If you want to exclude the ultrasonic volumetric protection, before arming the alarm system it is necessary to switch on
twice the instrument panel and then arming the alarm system. The exclusion will be active only for the next operating
cycle and will be signaled by three quick buzzer sounds.
If you want to exclude the ultrasonic volumetric protection and also the tilt sensor, before arming the alarm system it is
necessary to switch on three times the instrument panel and then arming the alarm system. The exclusion will be active
only for the next operating cycle and will be signaled by four quick buzzer sounds.
The same exclusion can be obtained by activating the instrument panel and pressing the ID-Tag B9.5 button for at least 1
second, the LED will stay on, then turn off the instrument panel and activate the alarm system within the next 20 seconds.
This exclusion will be active for any auxiliary modules also.
The alarm is deactivated by pressing the ID-Tag B9.5 radio control button, deactivation can be signaled by fl ashing of
turning indicators and by the switching off the LED.
If the radio control is not available when the door is opened, the alarm system produces an optical/acoustic alarm
cycle which can be interrupted by entering the Override security code or using an electronic key as described in the
"Emergency deactivation" chapter.
If the LED fl ashing after disarming informs that during the last protection period the system has performed one or more
alarm cycles. Reading the number of fl ashes it is possible to trace the type of alarm that has occurred.
The alarm memory will reset when the instrument panel is switched on for the fi rst time or after the next alarm arming.
TAG B9.5
SIREN
ELECTRONIC
KEY
AUXILIARY
PROTECTION
MODULES
TELEMATIC
SYSTEM
Confi guration used in vehicles without original remote control.

OPERATION

MANDATORY ADDITIONAL ACCESSORIES
(it is recommended to pair at least 2 programmed as REMOTE CONTROL)
To be selected among the 4 available devices (M03 – M06A – M07A – T78)
OPTIONAL ADDITIONAL ACCESSORIES
Simplify any emergency operations
To improve the vehicle protection
Allows georeferenced vehicle monitoring
(the T78 siren already performs this function)
