Parking Sensor Installation Technical Sheet
Dedicated system for LAMBORGHINI cars.
The technical information included in the following manual must be considered strictly approximate and the manufacturing company will not be
held liable in relation to said information. The technical staff appointed to installation is required to check, with due diligence and under their own
responsibility, the information provided herein based on the type of vehicle (ex. specifi c connection points for the model).
To achieve precise installation, we recommend the use of the tool kit
Part number 900000358
Part number 900000359
Advertisement
Related Manuals for Meta System 900000358
Summary of Contents for Meta System 900000358
- Page 1 Parking Sensor Installation Technical Sheet Dedicated system for LAMBORGHINI cars. Part number 900000358 To achieve precise installation, we recommend the use of the tool kit Part number 900000359 The technical information included in the following manual must be considered strictly approximate and the manufacturing company will not be held liable in relation to said information.
-
Page 2: Installation Regulations
INSTALLATION REGULATIONS • Before performing any operation, disconnect the negative pole on the battery. • The electronic control units of the kits must be installed exclusively inside the car cabin. • To attach them we recommend using velcro or straps, avoid drilling holes in the sheet metal on the car. -
Page 3: Electrical Connections
ELECTRICAL CONNECTIONS The required electrical connections described in the general installation manual must be set up on the 40- pole QUADLOCK connector installed behind the stereo. BLACK PURPLE/ BLACK RED/ BLACK... - Page 4 CAPSULE INSTALLATION POINTS Using the dedicated templates, mark the distances on the rear and front bumpers. REAR CABLE GLAND Using the supplied corrugated cable duct and silicone sheath, follow the existing route for the light cables to reach the cabin. NOTE: The templates provided at the end of the manual must be printed out making sure they are the correct size.
- Page 5 TAKING DOWN THE REAR BUMPER Proceed with taking down the rear bumper by following the instructions provided in procedure LB715 08 07 03. Also remove the black plastic support. REAR CAPSULE INSTALLATION We recommend preventively drilling a centring hole of 2.5mm Ø. Then, with a suitable 19 mm mill (included in the tool kit for Category 900000359) drill a hole in the bumper from the outside in.
- Page 6 REAR SENSOR CABLING Wrap the cables with the heat-resistant sheath, cat. 470 827 222, and secure the cabling to the crosspiece on the car. REAR BUMPER RE-ASSEMBLY Proceed with re-assembling the rear bumper by following the instructions provided in procedure LB715 08 07 03.
- Page 7 FRONT CABLE GLAND Using the supplied corrugated cable duct, follow the existing cable route to reach the cabin. TAKING DOWN THE FRONT BUMPER Proceed with taking down the front bumper by following the instructions provided in procedure LB715 08 07 03. Also take down the polyurethane vibration-damper support.
- Page 8 FRONT CAPSULE INSTALLATION NOTE: prior to installation it is necessary to remove the sensor’s support tabs as illustrated below. We recommend preventively drilling a centring hole of 2.5mm Ø. Then, with a suitable 19 mm mill (included in the tool kit for Category 900000359) drill a hole in the bumper from the outside in.
- Page 9 FRONT BUMPER RE-ASSEMBLY Proceed with re-assembling the front bumper by following the instructions provided in procedure LB715 08 07 03.
- Page 10 POSITIONING THE PARTS The rear management control unit must be set up in the module compartment behind the backrest on the passenger’s side. The front management control unit and the CAN BUS utility module must be set up over the GFA control unit located under the glove compartment, on the passenger’s side.
- Page 11 BUTTON INSTALLATION The front on/off button must be set up inside the plastic cover on the ceiling of the car, near the rear-view mirror. CABRIO COUPE’ Cut the template out being careful to use a ruler with millimetre scale to make sure it has printed out with zoom at 100%.
- Page 12 FRONT MASKING Mask the front system with the engine running.
- Page 13 REAR MASKING Mask the rear system with the engine running.
- Page 18 FRONT PARKING SYSTEM: LH REAR SIDE SENSOR...
- Page 19 REAR PARKING SYSTEM: RH REAR SIDE SENSOR...
- Page 22 Meta System S.p.A. con Socio Unico - Cap.Soc. 15.000.000,00 € i.v. - N° Reg. Impr. - Partita I.V.A. e Codice Fiscale 00271730350 - N° REA 120639 Sede Legale - Head Offi ce: Via T. Galimberti, 5 - 42124 Reggio Emilia (ITALY) - Telefax +39 0522 364150 - Tel. +39 0522 364111...
