OPERATION BY CAN BUS CONNECTION CONTROL: product setup
Before proceeding with the electrical installation it is necessary to confi gure the alarm for operation taking in care the
specifi c vehicle technical requirements and the customer requests.
NOTE: following are highlighted the essential programming steps for this specifi c operation.
NR° FUNCTION
1
Buzzer
2
Stimule check
3
Perimetrical alarm test
CENTRAL DOOR
4
LOCKING TIMING
5
BLINKER COMMAND
6
Horn/siren command
7
US sensitivity
8 Tilt enabling
9
Door protection
COMFORT DOOR
10
LOCKING
11
DEAD LOCK
12
Override Code
13
3 digits override code
14
Anti Carjacking
CAN Protocol
Trasponder
15 Long fl ashing Blinker
16
Immunity time
Delay on doors alarm
17
trigger
18 Electronic Keys cancel
Enable self learning for
19
Electronic Keys
20
Self arming
PROGRAMMING (advice for correct product set-up)
FUNCTION DESCRIPTION
Acoustic signals during ON/OFF
Acoustic signal with present
stimule
Check during the immunity time
Tempi di comando chiusure
Blinker command type (power or
Hazard button)
Pin12 brown wire command type
Ultrasound protection sensitivity
Tilt sensor function enabling
Continuous - repeats the door
alarm cycle if left open
Door locking command timing
Double closing command input
Emergency code
Code simplifi cation
See detailed manual for this
feature
Vehicle communication protocol
Emergency by reading the
original transponder
The Blinker fl ashing for a period
after fi nish the acoustic alarm cycle
Timing between the arming and
full protections
Timing between trigger and start
alarm
Allow to cancel all the Electronic
Keys if lose one of them
Function to memorize new
Electronic Keys
Function to enable the automatic
arming
SUGGESTED SET-UP
Disabled
Enable
Enable
0,5 sec
Single pulse on Hazard
button
Alternate
Sens. 3
Tilt Off
Continuous alarm
Comfort Off
Disabled
XXXXX
Disabled
Disabled
XXXXXXXXXX
On
On
Standard 26 Sec.
Short time 0,3 sec.
Disabled
10
NOTES
Evaluate with the customer whether
or not he wants On/Off signals
Don't modify it
Don't modify it
Only if the ID-TAG is combined and
the central door locking need to be
drive (see the vehicle data sheet)
Select the command depending of
the vehicle (see technical sheet)
If used to drive the clason/horn the
alternate type is suggested.
Change only if necessary
If tilt is enable fi x the alarm unit fi rmly
to the vehicle to avoid false alarms
Don't modify it
Select it by depending of the
vehicle (see technical sheet)
Evaluate with the customer
whether or not he wants disarming
by transponder
Shows the override code and allow its
modifi cation
Reducing the override code from 5
to 3 digits
Use it only if strongly request by the
customer
Select it by depending of the
vehicle (see technical sheet)
Evaluate with the customer
whether or not he wants disarming
by transponder
Defi ne it with customer
Don't modify it
Don't modify it
Cancel all the memorized Electronic
Keys
Enable the self learning to memorize
new Electronic Keys
Use it only if request by the customer
