The instructions included in this manual don't refer to specifi c vehicle models but are applicable in general to all motor
vehicles. The installation activities, product positioning, fi xing and electrical connections, have to be performed in a
workmanlike manner. The specialized technicians that have in charge the activity have to carefully check the car model
which is installing under his own responsibility.
Failure to comply with the above may lead to the loss of the device warranty.
GENERAL SPECIFICATIONS
Power supply:
Alarm control unit consumption:
Working temperature:
Immunity time:
Alarm arrows blinking:
Alarm cycle duration:
Alarm cycles for the different stimulations:
PROTECTIONS
Volumetric Protection:
Alarm input from auxiliary modules:
Perimeter Protections:
Tilt sensor protection:
Ignition Lock Relay:
Protection against ignition attempt:
Anti-Carjack:
SERVICES AND COMMANDS CAPACITY
Uscita Blocco Avviamento (pos. 23):
Uscita Indicatori di direzione (pos. 20-21):
Uscita pilotaggio pulsante Blinker (pos. 21):
Uscita comando clacson (pos. 12):
Uscita comando alzavetri (pos. 4):
Uscita comando moduli opzionali (pos. 8):
Uscite comando chiusure centralizzate (pos. 5-24):

MANAGEMENT FUNCTIONS

Alarm ON/OFF management configuration:
Emergency disarming:
LED optical signals:
Vehicle optical signaling:
Door open warning when arming:
Service Mode (Garage function):
Partial disarming:
Optional modules command:
Central door locking commands:
Ignition lock control:
Sirens control:
COMBINABLE SIRENS
Analogic Piezo siren:
LINBUS coded backup battery siren:
Wireless Bluetooth backup battery siren:
LINBUS coded backup battery Telematics siren:
SELECTING THE MOST SUITABLE ALARM FUNCTIONALITY CONSIDERING VEHICLE OR CUSTOMER'S NEEDS
The system gives the possibility, through a specifi c programming and combining accessories, to adapt to the customer's
safety needs or the specifi c technical features of the vehicle to be protected.
REMOTE CONTROL: (see dedicated chapter on page 5) This selection have to be used in vehicles without original remote
controls that needs the central door locking commands during arming and disarming. For this kind of system its
mandatory to combine the META EVOCAN with at least one ID-Tag B9.5 remote control and one of the available sirens
WITH CAN BUS CONNECTION: (see dedicated chapter on page 9) This selection have to be used in vehicles where a digital
network for managing services is present and the relative canbus protocol is available in the MetaSystem archive. This
kind of system requires only the combination of one the available sirens. It is possible to add one ID-Tag B9.5 remote
control if needs to have an additional remote control to the original one or if the user wishes to take advantage of the
additional protection provided by partial deactivation. In this case, if technically possible, it is recommended to connect
the central door locking commands also.
APPLICATION RULES ON THE VEHICLE

TECHNICAL SPECIFICATIONS

12Vdc (10V-15V)
Deactivated < 1,5mA - Activated < 5mA
-40°C +85°C
25 seconds
0.4 sec. ON; 0.4 sec. OFF
25 sec.
95/56/EC (European standards)
Eco/Doppler ultrasound system with 8 levels of sensitivity,
Positive input,
3 separate inputs to protect doors, boot and bonnet
3 Axes sensor embedded in the central unit
Electronic command with negative polarity
Checks of ignition signal +15/54 during arming status
Protection that can be activated pairing ID-TAG only
Max 1A Comando elettronico negativo.
Max 5A per linea; Comando elettronico positivo (vedi nota Fig. 21).
Max 1A Comando elettronico con polarità negativo.
Max 1A Comando elettronico negativo.
Max 100mA Comando elettronico positivo.
Max 100mA Comando elettronico positivo.
Max 1A Comando elettronico negativo.
Four command ON/OFF modes (Stand Alone ID-Tag – TX – CAN BUS – LIN BUS).
Override code from button/led, electronic keys, ID-Tag.
Signals to display the alarm status and alarm memories.
When the unit trigger an alarm it can drive flashing of turning indicators.
Signals if a door, boot or bonnet are open when arming the alarm.
Deactivates the alarm system and avoid any enabled selfarming
Perform the complete alarm disarming after recognition of its ID-Tag only.
This positive input command enable the optional protection modules activation.
During alarm arming and disarming by ID-TAG remote control gives a possibility
to drive the central door locking system.
By a dedicated command, it is possible to lock the vehicle starting when
the system is armed.
Depending of kind of paired siren the alarm has the possibility to drive them
with different command types, Bluetooth wireless connection (M07),
cable connection by LINBUS coded messages (M06-T78) or with analog signal (M03).
M03 - Sound level 114 dB
M06A - Sound level 115 dB
M07A - Sound level 115 dB
T78 - Sound level 115 dB
