Meta System META EVOCAN Installation Instructions Manual page 16

OPERATION BY LIN BUS CONNECTION: Electrical connection suggestions
NOTE: If the OPT Electronic Key
is installed, for the White/Black wire
LIN connection follow the diagram
in the Electronic Keys chapter.
BODY
SIREN
PRE-WIRING
(fi g. 26/27/28/29)
PRE-WIRING
FOR BONNET
PROTECTION
(fi g.14)
AUX CONNECTIONS
ENGINE
IMMOBILISATION
NEGATIVE
COMMAND
HORN RELAY
Fig. 4
(13)
(11)
(10)
(1)
PURPLE
DARK BLUE (23)
BROWN (12)
MOUNT
15A FUSE
(22)
RED
(19) BLACK
(8) PINK
(15) YELLOW
16
SENSOR FOR
VOLUME
PROTECTION
(RED)
SENSOR FOR
VOLUME
PROTECTION
(BLACK)
POSITIVE
BATTERY (+30)
EARTH
POSITIVE COMMAND
AUXILIARY MODULES
POSITIVE ALARM
INPUT
