7 INSTALLING THE POE SWITCH

The switch can be installed on the table-top by using the special feet provided or fastened to the wall using the screws and anchor not supplied with the
product.

7.1 LED OPERATING STATE

PWR-POWER LED INDICATION
On green The switch is powered
Off Switch is not powered
LED MAX
On green Indicates that the power delivered to the devices is greater than 43W.
Indicates that the power delivered to the connected devices has reached the maximum deliverable energy efficiency 58W.
Green flashing
It is not possible to power other devices.
Off Indicates that the power delivered to the devices is less than 43W.
LED Link/Act 1÷8
On green Port connection is working correctly.
Green flashing Indicates that data transmission / reception takes place via the Fast Ethernet network.
Off No connection.
LED PoE Ports
On green Indicates that a device is connected to a PoE port and that it receives power correctly.
Off No devices are connected to the PoE ports.
7.2 TECHNICAL SPECIFICATIONS
MIKRA2 DOOR UNIT REF. 1060/21
Power voltage POE: ................................................................................................................................................................................................. 44 ÷ 57 V
Local power voltage: ........................................................................................................................................................................................................ 48 V
Maximum consumption during video calls: ........................................................................................................................................................................ 3,5 W
Maximum stand-by consumption: ........................................................................................................................................................................................ 2 W
Frequency band: ........................................................................................................................................................................................................13,56 MHz
Output power (Max): ...................................................................................................................................................................................-13,1 dBμA/m @ 3m
LAN maximum operating distance (with POE or without POE) ............................................................................................................. 100 m with CAT5 cable
Max. distance from supplementary power supply: ......................................................................................25m with wire cross section area. 0.5 - 1.0 mm
Supported user key type: .................................................................................................................................................................................. Mifare (1125/54)
Name tag dimensions: ....................................................................................................................................................................................... 48.5 x 15.5 mm
Tag and button light: ............................................................................................................................................................................................... White LEDs
Dimensions (WxHxD): ................................................................................................................................................................................... 100 x 180 x 28 mm
Degree of protection of casings: ........................................................................................................................................................................................... IP55
Degree of protection from mechanical shocks: ....................................................................................................................................................................IK07
Working temperature range:............................................................................................................................................................................... -10 °C ÷ +55 °C
For the technical characteristics of the other devices, refer to the booklets supplied with the product.

8 KEY TO SYMBOLS

Symbol Explanation
Direct current power voltage
~
Alternating input voltage
See the installation manual of the device
DANGER - High Voltage
DANGER - Components critical to personal safety present

9 SIMPLIFIED EU DECLARATION OF CONFORMITY

Hereby, URMET S.p.A. declares that the radio equipment types: KIT VILLA IP MIKRA - BASIC Ref. 1060/634 are in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address: www.urmet.com
