7 INSTALLING THE POE SWITCH

The switch can be installed on the table-top by using the special feet provided or fastened to the wall using the screws and anchor not supplied with the
product.

7.1 LED OPERATING STATE

PWR-POWER LED INDICATION
On green The switch is powered
Off Switch is not powered
LED MAX
On green Indicates that the power delivered to the devices is greater than 43W.
Indicates that the power delivered to the connected devices has reached the maximum deliverable energy efficiency 58W.
Green flashing
It is not possible to power other devices.
Off Indicates that the power delivered to the devices is less than 43W.
LED Link/Act 1÷8
On green Port connection is working correctly.
Green flashing Indicates that data transmission / reception takes place via the Fast Ethernet network.
Off No connection.
LED PoE Ports
On green Indicates that a device is connected to a PoE port and that it receives power correctly.
Off No devices are connected to the PoE ports.
7.2 TECHNICAL CHARACTERISTICS
For the technical characteristics of the devices, refer to the booklets supplied with the product.

8 KEY TO SYMBOLS

Symbol Explanation
Direct current power voltage
~
Alternating input voltage
See the installation manual of the device
DANGER - High Voltage
DANGER - Components critical to personal safety present
