Connect Power Input and Relay Output
The power input and relay output wiring exits the Relay Controller through
the knockout mount on the enclosure.
1. Connect the power input wiring.
2. Connect the relay output wiring. The Relay Controller has two relay
output wires (12 AWG): Zone 1 is red and Zone 2 is red/white.
Note: When configured to single-channel mode, a single
3. Reinstall the junction box cover plate.
Neutral
Relay Controller
a. Connect the white wire (14 AWG) to the incoming neutral wire
from the breaker panel and the neutral wire of the lighting load.
b. Connect the black power input wire (12 AWG) to the line input
feed wire (hot) from the breaker panel.
a. Connect the Zone 1 relay output wire (red) to the hot input of the
first load.
b. Connect the Zone 2 relay output wire (red/white) to the hot input
of the second load.
DMX address controls both relays. If you are using only
one output, cap off the unused wires with wire nuts
(not included).
DMX-512A
Black
Line In
White
Red
Red/White
Page 6 of 16
Load 1
Load 2
