ETC Installation Guide
Relay Controller
Note: Follow all local code requirements for terminating
Connect DMX
1. Pull wiring to the junction box.
2. Terminate the DMX cable by following the steps in the termination kit
supplied with the unit.
Terminate DMX
Terminate the last device in the DMX data run for proper control
performance. To terminate the DMX data run at the Relay Controller,
connect the last two pins on the termination connector with a wire jumper
(not included).
Note: Because resistance is built into the Relay Controller, no
Relay Controller
wire.
• Notice that the harness wires on the controller are
pre-stripped for your installation convenience.
• Use appropriately sized wire nuts (not provided) to
secure each termination.
additional resistor is required to terminate the last
device in the DMX data run.
