E T C I n s t a l l a t i o n G u i d e
®
Unison Aero

Overview

The Aero Micro Relay Controller (UAMR) controls lighting loads when a
received input from a linked sensor or switch is changed.
The UAMR controls loads based on the following:
• switch actions from an Aero SmartClick Switch Station
• ambient light levels as monitored by an Aero Light Sensor
• occupancy state as monitored by an Aero Occupancy Sensor
• input from another Aero device
