ETC Unison Foundry Relay Controller Installation Manual page 10

ETC Installation Guide
Relay Controller
Task
4: Set the 1s digit of
the DMX address.
100s 10s
1s
201
5: Save the new DMX
address.
Note: The Relay Controller will exit DMX addressing mode
Relay Controller
What to do
Press the MODE button to
advance to the 1s digit.
Press the SET button to
set the 1s digit.
If the 1s digit in the new
DMX address is the same
as in the current DMX
address, you can keep the
digit by skipping to step 5.
Press the MODE button.
after 1 minute of inactivity. When this occurs, the
controller retains the DMX address that was saved
before you entered DMX addressing mode.
Page 10 of 16
What you will see
• The POWER LED indicator blinks once
to indicate that you are setting the 1s
digit of the DMX address.
• The SIGNAL LED indicator blinks the 1s
digit in the current DMX address. For
example, if the current DMX address is
201, the SIGNAL LED indicator blinks
once.
• If the SIGNAL LED indicator rapidly
blinks red, this means that you set the
10s digit to an invalid value. When this
occurs, the Relay Controller exits DMX
addressing mode without saving.
• The POWER LED indicator continues to
blink once to indicate that you are
setting the 1s digit of the DMX
address.
• The SIGNAL LED indicator blinks the
value that you set for the 1s digit in the
DMX address.
• The POWER LED indicator and SIGNAL
LED indicator return to their normal
LED Indicators and
functions (see
User Interface
on
• If the SIGNAL LED indicator rapidly
blinks red, this means that you set the
1s digit to an invalid value. When this
occurs, the Relay Controller exits DMX
addressing mode without saving.
page 12
).
