5.2. Device Configuration

The hardware components to reproduce the connection procedures in this guide are as
follows:
Personal computer
(Sysmac Studio and
MEXE02 installed,
OS: Windows 10）
LAN cable
Manufacturer
OMRON NX-series CPU Unit
(Built-in EtherNet/IP ports)
OMRON Switching hub
OMRON Sysmac Studio
―
Personal computer (OS: Windows 10)
―
LAN cable (STP (shielded, twisted-pair)
cable of Ethernet category 5 or higher)
ORIENTAL Driver
MOTOR
ORIENTAL Motor
MOTOR
ORIENTAL Motor cable
MOTOR
ORIENTAL Encoder cable
MOTOR
ORIENTAL EDS file
MOTOR
ORIENTAL Support software
MOTOR
―
USB cable
(USB 2.0-compliant, USB-Mini-B
connector)
―
Power supply (24 VDC for Controller)
―
Power supply (24 VDC for Switching hub)
―
Control power supply (24 VDC for Driver)
5．Applicable Devices and Device Configuration
NX102-1200
(Built-in EtherNet/IP ports)
Power
W4S1-05C
supply
LAN cable
USB cable
Name
Control power supply
LAN cable
Power supply
Model
NX102-1200
W4S1-05C
SYSMAC-SE2□□□
―
―
AZD-AEP
AZM46AC
CC010VZF-M
CC010VNF-E
AZD-AEP.eds
MEXE02
―
―
―
―
AZD-AEP
Main power supply
(single-phase 100-120V)
AZM46AC
Version
Ver.1.31
Ver.1.0
Ver.1.25
Ver.1.1
Ver.1.0
Ver.4.0.1.0
