Omron sysmac EtherNet/IP NJ Series Connection Manual page 30

5
Double-click Task Settings
under Configurations and
Setup in the Multiview Explorer.
The Task Settings Tab Page is
displayed in the Edit Pane.
Click the VAR Button.
6
Click the + Button displayed
under the column header
Variable to be refreshed in
Primary Task.
A new entry line is added to
Primary Task.
Select EIP002_OUT from the
pull-down list in the Variable to
be refreshed Column.
*The relevant data type is
automatically displayed for
each variable. There is no
need for you to set data types
yourself.
7
In the same way as step 6, add
all the previously set variables
to the Variable to be refreshed
Column (left).
7．EtherNet/IP Connection Procedure
27
