Outputs
Other outputs
Output of the speed setpoint (0 to 10 V=)
4.5

Type key

4.6 Operation on electronic start-up
controllers
4.7 Installation in potentially explosive
atmospheres
4.8

Scope of delivery

4.9

Accessories

5

Transportation and storage

5.1

Delivery

Installation and operating instructions • Wilo-Control EC/ECe-Booster • Ed.02/2023-08
Number of outputs
EC-B1 ... EC-B2 ...
− −
Key
1/2/3 = number of outputs, − = not available
Example: Wilo-Control ECe-B 2x12A-T34-DOL-WM
ECe Version with Easy Control switchgear:
- EC = switchgear for fixed-speed pumps
- ECe = switchgear for electronically controlled variable-speed pumps
B Control for pressure-boosting systems
2x Max. number of pumps that can be connected
12A Max. rated current per pump in amperes
T Mains connection:
M = alternating current (1~)
T = three-phase current (3~)
34 Rated voltage:
- 2 = 220/230 V
- 34 = 380/400 V
DOL Pump activation type:
- DOL = direct on line
- SD = star-delta
WM Wall fixation
Connect the switchgear directly to the pump and the mains. Intermediate switching of ad-
ditional electronic start-up controllers, e.g. a frequency converter, is not permitted!
The switchgear does not have its own explosion protection class. Do not install the
switchgear in potentially explosive areas!
Control EC-Booster
• Switchgear
• Installation and operating instructions
Control ECe-Booster
• Switchgear
• Installation and operating instructions
• Circuit diagram
• Float switch
• Pressure switch
• Electrode
• Pressure sensor 4 to 20 mA
NOTICE
Accessories installed as required
If the switchgear is delivered with a pressure-boosting system, the ac-
cessories may be pre-installed. Please check the order confirmation for
further information.
• After delivery, check product and packaging for defects (damage, completeness).
• Defects must be noted on the freight documentation.
• Defects must be notified to the transport company or the manufacturer on the day of
receipt of shipment. Claims cannot be asserted if the notification of defects takes place
at a later date.
EC-B3 ... ECe-B1 ...
− 1
en
ECe-B2 ... ECe-B3 ...
1 1
