Factory settings

8

Commissioning

8.1

Operator responsibilities

8.2

Activating the switchgear

8.2.1 Possible error message during ac-
tivation
Code* Faults
E006 Rotating field error
28
To reset the switchgear to the factory settings, contact customer service.
NOTICE
Observe additional documentation
• Carry out the commissioning measures in accordance with the install-
• Observe the installation and operating instructions for the connected
• Provide installation and operating instructions at the switchgear or at a place specially
reserved for it.
• Make the installation and operating instructions available in a language the personnel
can understand.
• Make sure that the installation and operating instructions have been read and under-
stood by all personnel.
• The installation site of the switchgear is overflow-proof.
• The switchgear is properly fused and earthed.
• Safety devices and precautions (incl. emergency off) for the entire system are switched
on and have been checked for problem-free operation.
• The switchgear is suitable for use under the specified operating conditions.
NOTICE! Rotating field monitoring and motor current monitoring are only available in
the Wilo-Control EC-Booster!
Depending on the mains connection and the basic settings, the following error message
may occur during activation. The error codes listed and their description apply to commis-
sioning. A complete overview can be found in Chapter "Error codes".
Cause
• Incorrect rotating field
• Operation with single-phase AC current
connection.
Installation and operating instructions • Wilo-Control EC/ECe-Booster • Ed.02/2023-08
Manual operation pump 3
If the operating button is pressed, pump 3 runs.
If the operating button is released, the pump switches off. The last set
operating mode is active again.
Pump 1 switch off.
Corresponds to the "off" value in menu 3.02.
Pump 2 switch off.
Corresponds to the "off" value in menu 3.03.
Pump 3 switch off.
Corresponds to the "off" value in menu 3.04.
Automatic mode, pump 1
Corresponds to the "Auto" value in menu 3.02.
Automatic mode, pump 2
Corresponds to the "Auto" value in menu 3.03.
Automatic mode, pump 3
Corresponds to the "Auto" value in menu 3.04.
ation and operating instructions for the overall system.
products (sensors and pumps) as well as the system documentation.
Remedies
• Establish a clockwise rotating field at the
mains connection.
• Deactivate rotating field monitoring
(menu 5.68)!
