Wilo-Control ESK, PSK
de Einbau- und Betriebsanleitung
en Installation and operating instructions
fr
Notice de montage et de mise en service
es
Instrucciones de instalación y funcionamiento
2 543 184-Ed.01 / 2015-12-Wilo
it
Istruzioni di montaggio, uso e manutenzione
ru Инструкция по монтажу и эксплуатации
Advertisement
Related Manuals for Wilo Control ESK Series
Summary of Contents for Wilo Control ESK Series
- Page 1 Pioneering for You Wilo-Control ESK, PSK de Einbau- und Betriebsanleitung Istruzioni di montaggio, uso e manutenzione en Installation and operating instructions ru Инструкция по монтажу и эксплуатации Notice de montage et de mise en service Instrucciones de instalación y funcionamiento 2 543 184-Ed.01 / 2015-12-Wilo...
- Page 2 Fig. 1: Fig. 2:...
- Page 3 Fig. 3:...
- Page 4 Fig. 4a: Fig. 4b: Fig. 4c: Fig. 4d: Fig. 4e: Fig. 4f:...
- Page 5 8.3.1 Installation with two electrodes ........................15 8.3.2 Installation with one electrode .......................... 15 8.3.3 Installation with flow meter ..........................15 8.3.4 Pumping operation ..............................15 8.3.5 Pressure boosting ..............................16 Maintenance............................16 Faults, causes and remedies........................16 Spare parts ............................17 WILO SE 12/2015...
-
Page 6: General
Acutely dangerous situation. Non-observance results in death or the most serious of injuries. WARNING! The user can suffer (serious) injuries. ‘Warning’ implies that (serious) injury to persons is proba- ble if this information is disregarded. Installation and operating instructions Wilo-Control ESK1, PSK1... -
Page 7: Safety Instructions For The Operator
Modifications to the product are only permissible after consultation with the manufacturer. Original spare parts and accessories authorised by the manufacturer ensure safety. The use of other parts will absolve us of liability for consequential events. WILO SE 12/2015... -
Page 8: Product Information
Protection class selector switch for low water protection On/off switch for time delay when using pressure switch or flow meter Connector for control panel circuit board Fuse holder low voltage fuse (0.8 A) Installation and operating instructions Wilo-Control ESK1, PSK1... -
Page 9: Installation And Electrical Connection
(see Fig. 2; item 4); beforehand, remove the bridge between terminals 5 + 6. Connect the cable to the terminal strip based on the intended application (see Fig. 2, item 4 and Fig. 4;. see Chapter 6.3). WILO SE 12/2015... -
Page 10: Check Direction Of Rotation (3-Phase Motor Only)
During the waiting period, the yellow signal lamp During the waiting period, the yellow signal lamp flashes (Fig. 1, item 2). flashes (Fig. 1, item 2). • Applying the electrode (see the pump operating instructions) Installation and operating instructions Wilo-Control ESK1, PSK1... -
Page 11: Pressure Boosting
The pump starts up but the flow rate is • The rotation speed is too low • Check the power supply and motor too low connection. • Incorrect direction of rotation • Switch two phases! WILO SE 12/2015... -
Page 12: Spare Parts
To avoid queries and incorrect orders, all data from the rating plate must be specified with every order. The spare parts catalogue can be found at the following address: www.wilo.com. Subject to change without prior notice. Installation and operating instructions Wilo-Control ESK1, PSK1...
