Step 1
continued
2 There are primarily 3 different styles of deadbolts (shown below)
found on most doors. Depending on which type yours is, you
may need to do a slight modification on your door hole (trim by
wood file or utility knife) to ensure the cable of the fingerprint
sensor is not pinched between the door and the lock.
A. NO RING
Does not require
door lock hole
modification.
B. MOUNTING RING
IMPORTANT:
4

REMOVE EXISTING DEADBOLT

C. ANTI-PRY SHIELD
Door Exterior
*Optional
Lock type B and C require
door hole modification. File
or trim door hole to avoid
cable from being pinched.
