FLEX TOUCH
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FLEX TOUCH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lockly FLEX TOUCH

Summary of Contents for Lockly FLEX TOUCH

  • Page 1 FLEX TOUCH USER MANUAL...

  • Page 2: Table Of Contents

    1.1 Product Features Section 2 - Product Overview 2.1 Product Overview - Exterior 2.2 Product Overview - Interior 2.3 Getting the Most From Your LOCKLY 2.4 Pair Lock with LOCKLY App 2.5 Resetting Your Lock 2.6 Low Battery 2.7 Changing the Battery Section 3 - Using Your Smart Lock 3.1 Adding a Fingerprint...

  • Page 3: Product Features

    9V battery that attaches to external contacts and your registered fingerprint. Access Profile Duplication Allows time saving, secure copying and pasting through the LOCKLY app of dupli- cate fingerprint and eKey profiles from one lock to another lock. Multi-door Locking Mode Easily program all your LOCKLY smart locks to lock simultaneously with one touch using the LOCKLY app, Google Assistant or Amazon Alexa.*...

  • Page 4: Product Overview - Exterior

    2.1 Product Overview - Exterior Key Cylinder Fingerprint Sensor 9V Backup Contacts SECTION 2.1...

  • Page 5: Product Overview - Interior

    2.2 Product Overview - Interior Battery Cover Battery Compartment (4 x AA Alkaline Batteries) Reset Button Program Button Alert (beep) speaker Thumb-turn SECTION 2.2...

  • Page 6: Getting The Most From Your Lockly

    2.3 Getting the Most From Your LOCKLY Thanks for purchasing your new LOCKLY. To get the most out of your lock be sure to read completely through this manual to learn all of its features and capabilities. LOCKLY smart locks are at their full potential when used with the free LOCKLY app.

  • Page 7: Pair Lock With Lockly App

    XXXXXXXX SCAN & SAVE 1. If you have not, download the LOCKLY app from the App Store or Google Play. 2. Open the App and create an account, or log into your existing account. 3. Select set up a new device.

  • Page 8: Resetting Your Lock

    “Pair Lock with LOCKLY app” on page 5. Reset Button Under battery cover Press Reset Button for one (1) second or till you hear a short beep See page 5 for re-pairing your lock to the LOCKLY app SECTION 2.5...

  • Page 9: Low Battery

    2.6 Low Battery Alert LOCKLY Flex Touch will notify you with a continuous beep that it's time to change the batteries before they reach critical level. You should replace the batteries immediately to avoid the lock from shutting down and auto locking.

  • Page 10: Changing The Battery

    • Replacement of batteries does not affect programmed data. • Replace only with new batteries. DO NOT mix with used batteries. Whenever batteries are replaced, reconnecting the smart lock to your smartphone app is required. To downloaded the app, visit: LOCKLY.com/app SECTION 2.7...

  • Page 11: Adding A Fingerprint

    3.1 Adding a Fingerprint LOCKLY Flex Touch can store up to 99 fingerprints. Fingerprints are added and registered using the free LOCKLY app for iOS or Android. Download the LOCKLY app from the App Store or Google Play then register a new fingerprint under Access >...
  • Page 12 Sensor can be cleaned by wiping with a lint-free microfiber cloth. On the LOCKLY app, select the LOCKLY Flex Touch you wish to add a fingerprint. Go to Access > Access Management >...
  • Page 13 3.1 Adding a Fingerprint (Continued) Enter a Fingerprint name to save the profile, then tap "Successfully Added" Tap "Add Another Fingerprint" to register additional fingers or tap "Done" . TIP: Scan the same finger more than once to increase accuracy. SECTION 3.1...

  • Page 14: Fingerprint Scanning Directions

    3.2 Fingerprint Scanning LOCKLY fingerprint sensors use powerful fingerprint reading algorithms that are able to detect most fingerprints accurately and quickly, even in less than ideal condi- tions. Knowing how to place your finger on the sensor correctly helps with consis- tent and fast recognition.

  • Page 15: Deleting Stored Fingerprints

    3.3 Deleting Fingerprints On the LOCKLY app, select the LOCKLY Flex Touch you wish to delete a fingerprint on. Go to Access Management > Fingerprint. Select the fingerprint by name you wish to delete. Select [DELETE USER] at bottom. Confirm. Once a registered fingerprint has been deleted it cannot be recovered.

  • Page 16: Adding Optional Secure Link

    Alexa and Google Assistant. Secure Link Wi-Fi Hub To set up the LOCKLY Secure Link and Door Sensor, launch the LOCKLY App, from the main menu drop down located on the upper left of the screen, select “Add a New Device”...

  • Page 17: Locking/Unlocking Lockly With Fingerprints

    4.1 Locking/Unlocking with Finger Unlocking Place a registered finger (to register see section 3.1.) to the fingerprint scanner on the low exterior of the lock. If your fingerprint is acknowledged, you will hear a “beep” a green LED will light, and the deadbolt will unlock.

  • Page 18: Locking/Unlocking Lockly With App

    4.2 Locking/Unlocking with App Open the LOCKLY app and select your lock (e.g., LOCKLY Flex Touch) tap the lock or unlock icon. You will also need the app in order to lock and unlock with Amazon Alexa or Google Assistant. To download, visit the link below or search “LOCKLY” in the App Store or Google Play.

  • Page 19: Locking/Unlocking Lockly With Physical Key

    4.3 Locking/Unlocking with Physical Key To unlock your lock using the physical key (included), insert your key and turn clockwise or counter clockwise to lock or unlock the door. SECTION 4.3...

  • Page 20: Locking And Unlocking With Voice Assistant Control

    Alexa, Unlock my front door.* Is my front door locked? Alexa, Hi Alexa, Is my front door unlocked? Lock my front door. *Unlock requests require additional voice security codes that can be configure in the LOCKLY app settings. SECTION 4.4...

  • Page 21: Rain Mode

    NOTE: when the lock enters Rain Mode, it’s recorded in the log history on the LOCKLY app. The app will also send a push notification to your mobile phone letting you know that the lock is in Rain Mode.

  • Page 22: Welcome Mode

    Enable this feature through the LOCKLY App. Go to > Settings > Enable Welcome Mode, then slide button to enable and set the specific time you require your door unlocked.

  • Page 23: Ebadge

    It requires them to download the free LOCKLY app and access can only be gained through the app (not the fingerprint reader). To set up and send a code in the LOCKLY app, go to > Access > eBadge (at top) > Add eBadge, then follow the on-screen prompts.
  • Page 24 5.1 eBadge (Continued) 7Y20LOCKLY Select type of access: either a valid period of time or ongoing reoccurring (can be revoked at anytime). Review and confirm access type. Share unique eBadge code. SECTION 5.1...

  • Page 25: Section 6 - Important Notes

    App. 9V Backup Access When your LOCKLY is out of power, you can temporarily activate the fingerprint sensor by using a 9V battery against the bottom of the exterior side of the smart lock. Please see Section 2.7 for more info.

  • Page 26: Section 7 - Cleaning Tips

    7.1 Cleaning Keeping your LOCKLY clean insurers optimal performance. Follow the recommen- dations below. DON’T • Don’t use abrasives, high • Use a microfiber cloth to Alkaline cleaners, or clean the fingerprint solvents to clean your lock. reader. • Don’t apply cleaners •...

  • Page 27: Section 8 - Safety Precautions

    8.1 Safety Precautions Read and remind all users of the following safety precautions LOCKLY Smart Locks do not have any user serviceable internal parts. Do not attempt to disassemble the lock. It may cause product damage and/or personal injury and will void any warranty.
  • Page 28 FCC Warning： This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 29 FLEX TOUCH We’re here to help! help@LOCKLY.com LOCKLY.com/help...
  • Page 30 LOCKLY Vision™ LOCKLY Flex Touch LOCKLY Secure, Secure Plus, Secure Pro, Secure Lux, Lux Com- pact, Model 6S, Model 7S, Flex Touch and LOCKLY Vision are keyless smart locks equipped with patented and advanced features such as the PIN Genie hack-proof keypad, 3D Finger- ®...
