Lockly FLEX TOUCH PRO Installation Manual page 16

Step 5
continued
When installing the wired door sensors, make sure the arrow on the
P
wired sensor
as possible.
Sensors can be positioned
on either left or right side
(see next page).
aligns to the arrow of the sensor magnet
2-3/8" (60mm)
Foam pad
2-3/4" (70mm)
PREPARING WIRED DOOR SENSOR
The sensors need to be as
close to level as possible. If
needed, use the adhesive
foam pad(s) to adjust the
height of the wired sensor.
16
Q
as close
(P)
3/4" (20mm)
Right
or
Left
(Q)
