Lockly FLEX TOUCH PRO Installation Manual page 18

Step 6
Plug the cable coming through mounting plate into the interior assembly
as shown. Tuck cable under eyelet hook and route to the right on
interior assembly.
X
Plug into Y
plug with red on socket - insert tightly.
X
Install Cable Remove Cable
1
, match red side of
Y
IMPORTANT:
If you need to disconnect this cable,
use a screwdriver to hold down the tab
(marked red) before carefully unplug-
2
ging. DO NOT FORCE as this may result
in damaging the lock.
18
INSTALLING THE INTERIOR ASSEMBLY
Push any excess cable that might
interfere with the back assembly
or the spindle/torque blade back
through the deadbolt door hole.
