1. Introduction

This 18Gbps HDMI Extender can extend high definition video / audio signal, RS-232, bi-directional
IR and internet signal, at the distance of up to 328ft / 100m between transmitter and receiver via a
single CAT6a/7 cable and support resolution up to 4K2K@60Hz 4:4:4. The Transmitter supports
ARC function and local audio extract. In addition, the extender is equipped with bi-directional IR
pass-through which allows for source and display control. It also supports USB KVM and PoC
function.
The extender offers the most convenient solution for HDMI extension via a single CAT
cable with long distance capability, and is the perfect solution for any application.

2. Features

HDCP 2.2 / HDCP 1.4 and DVI 1.0 compliant
Supports 18Gbps video bandwidth
Video resolution is up to 4k2k@60Hz YUV 4:4:4
The maximum transmission distance is 328ft / 100m via a single CAT6a/7 cable
Supports ARC (Audio Return Channel) function
With bi-directional IR, RS-232 and CEC pass-through
Supports USB KVM function
HDR, HDR10+, Dolby Vision and HLG function supported
Supports PoC (Power over Cable) function
Compact design for easy and flexible installation

3. Package Contents

1 × 18Gbps HDMI over HDBaseT Extender (Transmitter)
1 × 18Gbps HDMI over HDBaseT Extender (Receiver)
1 × IR Blaster Cable (1.5m)
1 × 20~60KHz IR Receiver cable (1.5m)
4 × Mounting Ear
2 × 3-pin Phoenix connector
1 × 24V/1A Locking Power adapter
1 × User Manual
