1. Introduction

The HDMI 18Gbps Audio Embedder could embed audio signals from digital optical or analog stereo
Line audio to HDMI output. Further, both input and output HDMI support video resolution up to
4K2K@50/60Hz (YUV444). It supports 10bits HDR (High Dynamic Range) pass through and HDMI
high resolution digital audio formats bypass, LPCM 2CH, Dolby TrueHD, Dolby Digital Plus, Dolby
Atmos a d DTS-HD Master Audio, audio sampling rate up to 192 kHz. HDCP 2.2 and CEC bypass
are supported.

2. Features

Embeds multi-channel optical (SPDIF) or Line analog audio to HDMI output
Optical audio supports LPCM 2CH, Dobly Digital 2/ 5.1CH, DTS 2/5.1CH
Analog audio supports PCM2.0
HDMI 2.0b (18Gbps), HDCP 2.2 and DVI 1.0 compliant
Video resolutions up to 4K2K@50/60Hz (YUV444)
Supports HDMI High Bit Rate (HBR) audio pass through
10bits HDR (High Dynamic Range) pass through
Supports CEC bypass

3. Package Contents

1 x HDMI 18Gbps Audio Embedder
1 x 5V/1A Power Adapter
1 x User Manual

4. Specifications

5
