  • Page 1 Optical Test System IQ-200 User Guide www.valuetronics.com...
  • Page 2 SINGAPORE 169876 EXFO ASIA- #03-29, Manhattan House Tel.: +65 6333 8241 · Fax: +65 6333 8242 PACIFIC (USA and Canada) 1 800 663-3936 TOLL-FREE www.exfo.com · info@exfo.com  © 2004 EXFO Electro-Optical Engineering Inc. All rights reserved. Printed in Canada.
  • Page 3 IQ-200 Optical Test System Instruction Manual Seventh Edition P/N: MAN-056-I .7ACE If the equipment described herein bears the symbol, the said equipment complies with the European Community Directive and Standards found in the Declaration of Conformity. If the equipment described herein bears an statement, the said equipment complies with the relevant Federal Communications Commission standards.
  • Page 4 EXFO Electro-Optical Engineering Inc. (EXFO). Information provided by EXFO is believed to be accurate and reliable. However, no responsibility is assumed by EXFO for its use nor for any infringements of patents or other rights of third parties that may result from its use.
  • Page 5 1 IQ-200 Optical Test System Overview ............1 IQ-203 Control Unit......................... 1 IQ-206 Expansion Unit ......................4 IQ-206 Expansion Card......................6 Remote Control of the IQ-200 Optical Test System..............8 2 Safety Information ..................9 Safety Conventions........................9 Safety Precautions ........................9 Electrostatic Discharge Precautions ..................
  • Page 6 Sharing the CD-ROM Drive from the PC ................79 Accessing the Remote CD-ROM from the IQ-203 Through a Network........80 Accessing the Remote CD-ROM from a PC Connected Directly to the IQ-203......81 Troubleshooting Direct Cable Connection ................85 Index........................87 IQ-200 www.valuetronics.com...
  • Page 7 ➤ Consult the dealer or an experienced radio/TV technician for help. ARNING Changes or modifications not expressly approved by EXFO Electro-Optical Engineering Inc. could void the user’s authority to operate the unit. Optical Test System www.valuetronics.com...
  • Page 8 EXFO, and externally, at an independent, qualified laboratory. All pre-qualification tests were performed at EXFO while all final tests were performed at UltraTech Engineering Labs Inc., a renowned test laboratory from Mississauga, Canada. This guarantees the unerring objectivity and authoritative compliance of all test results.
  • Page 9 Card inserted in a PC. IQ-203 Control Unit The IQ-203 is the mainframe of the IQ-200 Optical Test System. The IQ-203 controls all the modules, whether they are inserted in the IQ-203 itself or in an IQ-206 Expansion Unit. The standard IQ-203 integrates a Pentium MMX microprocessor PC architecture.
  • Page 10 IQ-200 Optical Test System Overview IQ-203 Control Unit IQ-203 Front Panel 3.5” high density Integrated floppy disk drive VGA display Loads or saves data on floppy disk. Front panel keys Front panel mouse IQ modules Activate different software Activates software...
  • Page 11 IQ-200 Optical Test System Overview IQ-203 Control Unit IQ-203 Back Panel Modem card Certification and Additional DB9 serial port (optional) and ports warning label (optional) GPIB port (optional) Fuse holder Nameplate AC socket IQ-206 port Monitor port Keyboard port Mouse port (PS/2)
  • Page 12 The IQ-206 is called the expansion unit of the IQ-200 Optical Test System because it is usually used to expand the module capacity of an IQ-203 Control Unit. You can link up to four IQ-206 Expansion Units to an IQ-200 Optical Test System. Each IQ-206 Expansion Unit can support up to six modules, which are either controlled from an IQ-203 Control Unit or an IQ-206 Expansion Card, via the Windows compatible IQ-200 Software.
  • Page 13 IQ-200 Optical Test System Overview IQ-206 Expansion Unit IQ-206 Back Panel Certification and Fuse warning label holder Nameplate IQ output port IQ input port Used to link the unit Used to link the unit to another IQ-206 to an IQ-203 Control...
  • Page 14 For details about installing the software on a PC, see Installing the ➤ IQ-200 Software on page 27. For help with the use of the software, see Using the IQ-200 Optical Test ➤ System on page 35. Your IQ-206 Expansion Card will look different depending if it is an ISA or PCI card and the installation method will be different.
  • Page 15 IQ-200 Optical Test System Overview IQ-206 Expansion Card PCI Expansion Card Diagram ISA Expansion Card Diagram DIP switches Optical Test System www.valuetronics.com...
  • Page 16 IQ-200 Optical Test System Overview Remote Control of the IQ-200 Optical Test System Remote Control of the IQ-200 Optical Test System In addition to stand-alone operation, the IQ-200 Optical Test System can be remotely controlled through one of the following methods: GPIB interface ➤...
  • Page 17 Failure to comply with these precautions or with specific indications elsewhere in this manual violates safety standards of intended use of the unit. EXFO assumes no liability for the user's failure to comply with these requirements. AUTION...
  • Page 18 ARNING The IQ-203 Control Unit was designed to be a test instrument that should not be opened by users. EXFO is not responsible for any personal injury incurred while attempting internal service of the IQ-203 Control Unit or IQ-206 Expansion Unit.
  • Page 19 Safety Information AC and Power Cable Requirements AC and Power Cable Requirements The IQ-203 can operate from any single-phase AC power source between 100 V and 240 V (50/60 Hz). The maximum input current of the IQ-203 is 1.5 A. The IQ-206 can operate from any single-phase AC power source between 100 V and 240 V (50/60 Hz).
  • Page 20 Do not use an extension cord without a protective conductor. ➤ Before powering ON the unit, connect the protective ground terminal of the unit to a protective conductor using the unit power cord. Do not tamper with the protective ground terminal. ➤ IQ-200 www.valuetronics.com...
  • Page 21 Installing and Connecting the IQ-200 Hardware The IQ-200 Optical Test System can include up to four IQ-206 Expansion Units connected in a daisy chain with an IQ-203, allowing 27 single-slot linked modules. Mounting all these units into a standard 19-inch...
  • Page 22 Installing and Connecting the IQ-200 Hardware Setting Up the IQ-200 for Rack-Mount Use Setting Up the IQ-200 for Rack-Mount Use Each IQ-203 Control Unit and IQ-206 Expansion Unit has two rear cooling fans. Mount or position the units so that air can circulate freely around them.
  • Page 23 Installing and Connecting the IQ-200 Hardware Setting Up the IQ-200 for Rack-Mount Use 2. Power OFF the IQ-203/IQ-206 and remove the four bottom cover screws under the IQ-203/IQ-206 as shown below. 3. Slide the IQ-203/IQ-206 inward through the rack-mount front panel, with the front of the unit facing you.
  • Page 24 Installing and Connecting the IQ-200 Hardware Setting Up the IQ-200 for Rack-Mount Use 4. Use the flange screws and flat washers supplied with the kit to secure the IQ-203/IQ-206 onto the rack-mount flanges. 5. Insert the rack-mounted IQ-203/IQ-206 into the cabinet as shown below and secure in place using the hardware supplied with the rack.
  • Page 25 Installing and Connecting the IQ-200 Hardware Connecting IQ-206 Expansion Units to an IQ-203 Control Unit Connecting IQ-206 Expansion Units to an IQ-203 Control Unit Up to four IQ-206 Expansion Units can be connected to the IQ-203 Control Unit, which represents a total of 27 single-slot modules. The necessary...
  • Page 26 Installing and Connecting the IQ-200 Hardware Connecting IQ-206 Expansion Units to an IQ-203 Control Unit IQ-203 Control Unit LR107723 LISTED Test Equipment E182628 XXXX 100-240 V 50/60 Hz 1.5 A F3AL250 V This device complies with part 15 of the FCC rules. Operation is...
  • Page 27 Installing and Connecting the IQ-200 Hardware Installing the IQ-206 Expansion Card Installing the IQ-206 Expansion Card The IQ-206 Expansion Card is available in two models: ISA and PCI. Both cards provide the same functionality, but the installation procedure is not exactly the same, as explained below.
  • Page 28 Take note of your DIP switch settings. You will be asked to enter these settings at the end of the IQ-200 Software installation, so the IQ-200 Software can locate the IQ-206 Expansion Card within the system.
  • Page 29 Installing and Connecting the IQ-200 Hardware Installing the IQ-206 Expansion Card The I/O port address is a hexadecimal number and must be any multiple of 020h within the range of 060h to 03C0h. The hexadecimal address is then converted into binary code so the DIP switches can be set to the “1”...
  • Page 30 Installing and Connecting the IQ-200 Hardware Installing the IQ-206 Expansion Card The possible IRQ numbers and their corresponding DIP switch settings are listed in the table below. DIP Switch Setting Number IRQ5 IRQ7 IRQ9 IRQ10 IRQ11 IRQ12 IRQ15 Note: The recommended IRQ number for the IQ-206 Expansion Card is IRQ9.
  • Page 31 Installing and Connecting the IQ-200 Hardware Installing the IQ-206 Expansion Card Adding a PCI Card in Microsoft Windows Microsoft Windows will detect a new PCI card when you reboot your computer and automatically offer you to install new drivers. You will need access to a CD-ROM drive for this installation.
  • Page 32 CD drive and check only the Specify a location box. Use the Browse... button to locate it and click on Next to start searching. MPORTANT EXFO recommends that you do not use the Floppy disk drives or CD-ROM drive options. The Wizard may not recognize your drives using these options.
  • Page 33 Installing and Connecting the IQ-200 Hardware Connecting IQ-206 Expansion Units to an IQ-206 Expansion Card Connecting IQ-206 Expansion Units to an IQ-206 Expansion Card Once installed into a PC, the IQ-206 Expansion Card can control up to four IQ-206 Expansion Units, which represents a total of 24 single-slot modules.
  • Page 34 Installing and Connecting the IQ-200 Hardware Connecting IQ-206 Expansion Units to an IQ-206 Expansion Card IQ-206 Expansion Card installed into a PC Use only with a 250V fuse Employer uniquement avec un fusible de 250V F3AL250 V LR107723 LISTED Test Equipment...
  • Page 35 IQ-200 Software Installing the IQ-200 Software If you have purchased an IQ-203 Control Unit, the IQ-200 Software should have been pre-installed at the factory. If you are to use the software with an IQ-206 Expansion Card or if you ever need to reinstall it on your IQ-203 Control Unit, use the CD-ROM provided with your IQ-200 Optical Test System.
  • Page 36 6. In the Select Components step, choose the software components you want to install on your IQ-203 or PC. 6a. Check the boxes corresponding to the components to install. Program Files: necessary files to use the IQ-200 Optical Test ➤ System software. This option is mandatory.
  • Page 37 Installing and Configuring the IQ-200 Software Installing the IQ-200 Software 7. In the Select GPIB Components step, choose the type of GPIB material you will use with your system. 7a. Select the radio button corresponding to your GPIB setup. Examples are given below: None: if you have no GPIB card in your system.
  • Page 38 12. If a Service Pack has been included with your shipment, you should install it now. Service Packs provide the latest software updates. Note: For more information about using the IQ-200 Optical Test System and its software, see Using the IQ-200 Optical Test System on page 35.
  • Page 39 IRQ and base I/O address. The IQ-200 Software is configured through a small utility automatically accessed at the end of the IQ-200 Software installation. You can also access this utility at any time after the installation.
  • Page 40 The hardware equipment (IQ-203 Control Unit or IQ-206 Expansion Card) should be automatically detected. MPORTANT When running on an IQ-203 Control Unit, the IQ-200 Software automatically configures itself to the default settings. In this case, you should not change the parameters in the IQ Configuration Tool.
  • Page 41 Installing and Configuring the IQ-200 Software Uninstalling the IQ-200 Software Uninstalling the IQ-200 Software To uninstall the IQ-200 Software, 1. In the Windows Start menu, select Control Panel. 2. Select the Add/Remove Programs icon to display a list of all the software installed on your unit.
  • Page 42 This page is intentionally left blank. www.valuetronics.com...
  • Page 43 Getting Started with the IQ-203 Control Unit Before powering on the IQ-203 Control Unit and IQ-206 Expansion Unit, EXFO recommends that you carefully read the previous sections of this instruction manual to ensure that you comply with the safety precautions, power requirements, and ➤...
  • Page 44 During this test, the LED push buttons of all IQ modules light up in sequence. For more information about the use of the IQ-200 Software, see Understanding the IQ-200 Software on page 41. If you encounter any problems, see Maintenance and Troubleshooting on page 59.
  • Page 45 Getting Started with the Expansion Card Getting Started with the Expansion Card Before powering on the PC with an IQ-206 Expansion Card and the IQ-206 Expansion Units, EXFO recommends that you carefully read the previous sections of this instruction manual to ensure that ➤...
  • Page 46 Microsoft Windows (it is usually loaded automatically). 5. From the Windows Start menu, select Programs > EXFO > IQ Shell. As the IQ-200 Software loads, it performs a self test to demonstrate that communication has been established with IQ modules. During this test, LED push buttons of all IQ modules light up in sequence.
  • Page 47 To insert an IQ module in the IQ-200 Optical Test System, 1. Exit the IQ-200 Software and power off the IQ-203 and IQ-206. If you are controlling modules from a PC, you do not need to turn the PC off.
  • Page 48 IQ module from the IQ-203 Control Unit or IQ-206 Expansion Unit. 1. Exit the IQ-200 Software and power off the IQ-203 and IQ-206. If you are controlling modules from a PC, you do not need to turn the PC off.
  • Page 49 Green icon with a frame. with no frame. The IQ module icons represent the modules detected by the IQ-200 Optical Test System at power up. The module icon indicates the type of module and its position in the IQ-203 Control Unit or IQ-206 Expansion Unit. The position is represented by a number, telling in which unit the module is inserted (0 for the IQ-203 ➤...
  • Page 50 Using the IQ-200 Optical Test System Understanding the IQ-200 Software Using the Front Panel Mouse The front panel mouse operates as a standard computer mouse. Hold Button To initiate mouse dragging. Arrow Buttons To move the mouse pointer. Right Button To display contextual menus.
  • Page 51 When several monitor windows are open, switch between them. ➤ ➤ When all IQ-200 front panel lights are turned off (see Activating and Deactivating the Front Panel Lights on page 46), return to the normal LCD and LED displays. Move between window items (as a tab).
  • Page 52 Typing Values with the Software Keypad When an external keyboard is not available, you can use the numeric or alphanumeric software keypad to enter data in the IQ-200 Software. To enter values using the software keypad, 1. Double-click in the box or field where a value must be entered to display the appropriate keypad window.
  • Page 53 Using the IQ-200 Optical Test System Customizing the IQ-200 Optical Test System Customizing the IQ-200 Optical Test System Selecting an LCD or CRT Screen You can select to have the software displayed on the built-in screen of the IQ-203 Control Unit or on an external monitor.
  • Page 54 Activating and Deactivating the Front Panel Lights You can switch off all lights on all screens and module lights on the IQ components. This is useful when you need to use the IQ-200 Optical Test System in a dark environment.
  • Page 55 Using the IQ-200 Optical Test System Customizing the IQ-200 Optical Test System Activating and Deactivating the Front Panel Keys You can disable all front panel keys on your IQ-203 Control Unit to deny user intervention while your system is running.
  • Page 56 3. Click on OK to accept the changes. Selecting and Configuring a Printer The printer selection procedure for the IQ-200 Optical Test System is the same as for any Windows-compatible software. Refer to the Microsoft Windows documentation for further details.
  • Page 57 Using the IQ-200 Optical Test System Customizing the IQ-200 Optical Test System Renaming Modules You can customize the text appearing in the title bar of a module application. This may be useful when you use several similar modules. To modify the module name, 1.
  • Page 58 Using the IQ-200 Optical Test System Customizing the IQ-200 Optical Test System Setting the Display Resolution for Module Applications You can set all module applications to automatically launch in 640 x 480 display resolution. Otherwise, applications will launch in the default resolution of your PC.
  • Page 59 Using the IQ-200 Optical Test System Customizing the IQ-200 Optical Test System Opening and Saving a Software Configuration Configuration files allow you to store commonly used parameters to reuse them later. Parameters that are saved include: position and size of monitor windows and module icons ➤...
  • Page 60 The main window of a module application contains all module operation commands. As an example, the main window of the IQ-1100 Power Meter application is shown below: The IQ-200 Software is based on the Microsoft Windows operating system, so most module applications use standard Windows elements, such as: Radio buttons...
  • Page 61 Using the IQ-200 Optical Test System Starting and Using Module Applications Note: For details about a particular module application, refer to the instruction manual of the IQ module. A list of available IQ modules is given in IQ Modules and Typical Applications on page 71.
  • Page 62 Using the IQ-200 Optical Test System Displaying the Module Monitor Window Displaying the Module Monitor Window The monitor window of a module is a small window containing basic operation information for quick reference. It is ideal for use in tile format on the screen (27 monitor windows can be viewed simultaneously).
  • Page 63 Using the IQ-200 Optical Test System Displaying the Module Monitor Window Arranging Monitor Windows on the Screen To arrange all open monitor applications on the screen in a standard Windows cascade format, select Cascade from the Window menu. To arrange all open monitor applications on the screen in a standard Windows tile format, select Tile from the Window menu.
  • Page 64 Controlling the IQ-200 Remotely Controlling the IQ-200 Remotely The status bar indicates the module control status as described in the following table. For more information about remotely controlling the IQ-200 Optical Test System, refer to the GPIB and Application Development Guide. Indication...
  • Page 65 Using the IQ-200 Optical Test System Getting Help in the IQ-200 Software Getting Help in the IQ-200 Software The following table describes the possible ways to obtain help or information from the Help menu: Option Function Online Manual Opens this instruction manual in PDF format. You need to have Adobe Acrobat Reader installed on your IQ-200 Optical Test System.
  • Page 66 Units, you must exit the IQ-200 Software and shut down Microsoft Windows. To exit the IQ-200 Software and Microsoft Windows, 1. In the IQ-200 Optical Test System main window, select Exit from the File menu. Click on in the top right corner of the main window.
  • Page 67 Maintenance and Troubleshooting The IQ-200 Optical Test System family components have been designed to require a minimum of maintenance and provide reliable operation for many years. In addition, the IQ-203 has the same characteristics as a computer, therefore, similar care should be taken.
  • Page 68 Use only with a 250V fuse Employer uniquement avec un fusible de 250V 3. Verify and replace the fuses if necessary. 4. Ensure that the fuses are firmly in the holder prior to reinsertion. 5. Firmly push the holder back into place. IQ-200 www.valuetronics.com...
  • Page 69 «FILE0002.CHK», etc. In the Windows environment, a ScanDisk is automatically performed at power up every time the IQ-200 Optical Test System has not been properly shut down. It is recommended to verify the «.CHK» files from time to time and delete the needless ones to free disk space.
  • Page 70 IQ-203. Exit the IQ-200 Software and access the Windows Control Panel. Double-click on Display. In the Improper color scheme LCD flickers Display Properties window, choose setting the Appearance tab.
  • Page 71 Troubleshooting the IQ-206 Expansion Card Problem Probable Cause Recommended Action ➤ The IQ-206 Expansion 1. Power off the PC running the IQ-200 Unit is not powered on. Software and power off the IQ-206 Expansion Unit. The modules are not ➤...
  • Page 72 ➤ Contacting the Customer Service Group If you encounter any difficulty while using this product, please call EXFO at one of the offices listed below. Our Customer Service Group is available in North America from 7:30 a.m. to 8:00 p.m. (Eastern Time), Monday to Friday.
  • Page 73 Technical Specifications Electrical Specifications IQ-203 IQ-206 IQ-206 Control Unit Expansion Unit Expansion Card Supply voltage 100 to 240 VAC 100 to 240 VAC — Line frequency 50 to 60 Hz 50 to 60 Hz — Maximum input current 1.5 A 3.0 A —...
  • Page 74 (0° to +55°C) Storage temperature -4° to 140°F -40° to 158°F -4° to 140°F (-20° to +60°C) (-40° to +70°C) (-20° to +60°C) Relative humidity (non-condensing) (non-condensing) (non-condensing) Maximum altitude 6000 ft./2000 m 6000 ft./2000 m Pollution degree IQ-200 www.valuetronics.com...
  • Page 75 EXFO Electro-Optical Engineering Inc. (EXFO) warrants this equipment against defects in material and workmanship for a period of two years from the date of original shipment. EXFO also warrants that this equipment will meet applicable specifications under normal use. During the warranty period, EXFO will, at its discretion, repair, replace, or issue credit for any defective product.
  • Page 76 Warranty Liability Liability EXFO shall not be liable for damages resulting from the use of the purchased product, nor shall be responsible for any failure in the performance of other items to which the purchased product is connected or the operation of any system of which the purchased product may be a part.
  • Page 77 5. Return the equipment, prepaid, to the address given by the support personnel. Be sure to write the RMA on the shipping slip. EXFO will refuse and return any package that does not bear an RMA.
  • Page 78 This page is intentionally left blank. www.valuetronics.com...
  • Page 79 IQ Modules and Typical Applications List of IQ Modules The following table lists the IQ modules available when this instruction manual was printed. To obtain the most recent information or for further details, please contact EXFO. Module Module Module Module...
  • Page 80 Testing Insertion loss Optical return loss Polarization dependant loss Isolation and crosstalk Polarization mode dispersion DWDM Passive Component Testing Insertion loss vs. wavelength Optical return loss vs. wavelength Polarization dependant loss vs. wavelength Isolation and crosstalk vs. wavelength IQ-200 www.valuetronics.com...
  • Page 81 IQ Modules and Typical Applications Typical Applications for IQ Modules System Testing Noise simulation Tx-Rx Bit error rate (BER) Active Component Testing EDFA Photodetector Laser diode Other Applications Calibration Fiber characterization Optical Test System www.valuetronics.com...
  • Page 82 This page is intentionally left blank. www.valuetronics.com...
  • Page 83 The IQ-9600 Utility Module provides a secure, standardized way of integrating components such as couplers, isolators, filters, and Bragg gratings into the IQ-200 Optical Test System. Without such a module, these passive optical elements would end up loose on your workbench. This can cause damage or affect their adjustment.
  • Page 84 Using the IQ-9600 Utility Module Exploded View of Single-Slot Utility Module Exploded View of Single-Slot Utility Module IQ-200 www.valuetronics.com...
  • Page 85 Using the IQ-9600 Utility Module Exploded View of Double-Slot Utility Module Exploded View of Double-Slot Utility Module Optical Test System www.valuetronics.com...
  • Page 86 This page is intentionally left blank. www.valuetronics.com...
  • Page 87 Accessing a Remote CD-ROM Drive with the IQ-203 To access an external CD-ROM drive with your IQ-203 Control Unit, you may use either a PC accessed through a network or one connected directly to your IQ-203. Using the network is easier if you have access to it from your IQ-203, but both methods are explained in this section.
  • Page 88 You must do this from the PC itself. 2a. Select Start > Settings > Control Panel to start the Control Panel. 2b. Double-click on Network and select the Identification tab. 2c. Note the computer name for later use (circled in the illustration). IQ-200 www.valuetronics.com...
  • Page 89 Note: The direct method transfers data slower than a network connection. Connecting the PC to the IQ-203 To connect a PC to your IQ-203, 1. Use a standard LapLink Parallel Cable or a LapLink Serial Cable (EXFO’s GP-216). Both are illustrated below: Serial connector Parallel connector Optical Test System...
  • Page 90 The Microsoft IPX/SPX-compatible protocol must be installed on both systems for the connection to work. To configure the network protocols, 1. Select Start > Settings > Control Panel to start the Control Panel. 2. Double-click on Network and select the Configuration tab. IQ-200 www.valuetronics.com...
  • Page 91 Accessing a Remote CD-ROM Drive with the IQ-203 Accessing the Remote CD-ROM from a PC Connected Directly to the IQ-203 3. Check if the IPX/SPX-compatible protocol is available in the upper list. If not, add it as follows: 3a. Click on Add..., then double-click on Protocol. 3b.
  • Page 92 1b. If it is not already done, set the to Host computer set up to listen by clicking on Change... and going through the proposed steps. When you are done, the host is ready to accept a connection. IQ-200 www.valuetronics.com...
  • Page 93 Ensure that the CD-ROM drive is shared on the be established, but I host computer and that the files are not cannot access my files. protected from remote access. If you are still experiencing connection problems, do not hesitate to contact EXFO. Optical Test System www.valuetronics.com...
  • Page 94 This page is intentionally left blank. www.valuetronics.com...
  • Page 95 46 CRT screen ...........45 blank module ..........75 customer service ........64, 68 brightness buttons ........2 customizing the IQ-200 Optical Test System 45 button to adjust brightness ......... 2 to adjust contrast........2 DDE (Dynamic Data Interchange)....8 to power off the IQ-203......2 DEFRAG command........61...
  • Page 96 47 inserting a module........39 functions ..........43 installing location ........... 2 IQ-200 Optical Test System ....13 relation with software buttons ....43 IQ-200 Software........27 front panel lights IQ-206 Expansion Card......19 activating and deactivating....46 ISA card..........
  • Page 97 ..........59 power on ......... 35, 37 models available........19 product line ..........1 power consumption .......19 turning off ..........58 requirements..........19 IQ-200 Software technical specifications ......65 About window........57 troubleshooting ........63 installation description......27 IQ-206 Expansion Unit installation procedure ......27 back panel..........5...
  • Page 98 IQ-206 Expansion Card19 exiting............ 53 powering on starting ..........53 the IQ-200 Optical Test System ..35, 37 module monitor window the IQ-203 Control Unit ......36 arranging ..........55 the IQ-206 Expansion Unit ....36, 38 closing ...........
  • Page 99 Index remote control IQ-206 Expansion Card......65 GPIB ............8 IQ-206 Expansion Unit ......65 of the IQ-200 Optical Test System.... 8 mechanical ..........65 RS-232 ............. 8 storage Windows DDE .......... 8 space............57 Windows OLE........... 8 temperature ...........64 remote, status bar ........56 removing the module ........
