1 Introducing the IQS-2600B
Tunable Laser Source

General Information

The IQS-2600B Tunable Laser Source addresses the testing requirements
for dense WDM component testing in the C- and L-bands.
Output connector
Active LED
Monitor output connector
LED push button
The source has a medium coherence length that avoids problems such as
connector-induced interference and it is relatively immune to vibration. Its
linewidth is made up of several longitudinal modes that are present
simultaneously, resulting in no mode-hop-related measurement problems.
It also features a high-accuracy encoder for consistency in your results.
Your module may also feature the possibility to enable or disable the
automatic level control (ALC).
Tunable Laser Source
OUTPUT
ACTIVE
MONITOR
OUTPUT
IQS-2600B
Tunable Laser Source
Trigger In connector
TRIG IN
Trigger Out connector
TRIG OUT
Retaining screw knob
1
