  • Page 1 User Guide IQS-2100 Light Source for IQS Platforms...
  • Page 2 Engineering Inc. (EXFO). Information provided by EXFO is believed to be accurate and reliable. However, no responsibility is assumed by EXFO for its use nor for any infringements of patents or other rights of third parties that may result from its use.

  • Page 3: Table Of Contents

    Contents Contents Certification Information ......................v 1 Introducing the IQS-2100 Light Source ............1 Main Features .........................1 Available Models ........................2 Typical Applications ........................2 Conventions ..........................3 2 Safety Information ..................5 3 Getting Started with Your Light Source ............. 7 Inserting and Removing Test Modules ..................7 Starting the Light Source Application ...................11...
  • Page 4 9 Warranty ......................49 General Information ......................49 Liability ..........................49 Exclusions ..........................50 Certification ..........................50 Service and Repairs .......................51 EXFO Service Centers Worldwide ..................52 A Technical Specifications ................53 B SCPI Command Reference ................55 Quick Reference Command Tree ...................56 Product-Specific Commands—Description ................57 Index .........................73...

  • Page 5: Certification Information

    F.C.C. Information Electronic test equipment is exempt from Part 15 compliance (FCC) in the United States. However, compliance verification tests are systematically performed on most EXFO equipment. Information Electronic test equipment is subject to the EMC Directive in the European Union.
  • Page 6 DECLARATION OF CONFORMITY Application of Council Directive(s): 73/23/EEC - The Low Voltage Directive 89/336/EEC - The EMC Directive And their amendments Manufacturer’s Name: EXFO Electro-Optical Engineering Inc. Manufacturer’s Address: 400 Godin Avenue Quebec, Quebec Canada, G1M 2K2 (418) 683-0211 Equipment Type/Environment: Test &...

  • Page 7: Introducing The Iqs-2100 Light Source

    Source Main Features The IQS-2100 Light Source is designed for scientific and industrial applications using the IQS Platforms. The IQS-2100 Light Source includes a choice of multimode LEDs and temperature-stabilized single-mode Fabry-Perots laser emitters, in single- and dual-wavelength configurations, for both singlemode and multimode test applications.

  • Page 8: Available Models

    For easy repeat access, the software stores multiple power level and modulation configurations. Its Windows-based software allows the IQS-2100 Light Source to integrate easily into any test system. The IQS-2100 Light Source supports local control (via the IQS Manager software) and remote control (through GPIB, RS-232, or Ethernet TCP/IP using SCPI commands or the provided LabVIEW drivers).

  • Page 9: Conventions

    Introducing the IQS-2100 Light Source Conventions Conventions Before using the product described in this manual, you should understand the following conventions: ARNING Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. Do not proceed unless you understand and meet the required conditions.

  • Page 11: Safety Information

    Safety Information ARNING Do not install or terminate fibers while a light source is active. Never look directly into a live fiber and ensure that your eyes are protected at all times. ARNING Use of controls, adjustments and procedures for operation and maintenance other than those specified herein may result in hazardous radiation exposure.

  • Page 13: Getting Started With Your Light Source

    Getting Started with Your Light Source Inserting and Removing Test Modules AUTION Never insert or remove a module while the controller unit and its expansion units are turned on. This will result in immediate and irreparable damage to both the module and unit. To insert a module into the controller or expansion unit: 1.
  • Page 14 6. While applying slight pressure to the module, turn the retaining screw knob (located at the bottom of the panel) clockwise until the knob is horizontal. This will secure the module into its “seated” position. IQS-2100...
  • Page 15 Note: You can insert IQ modules into your controller or expansion unit; the IQS Manager software will recognize them. However, the IQS-2100 locking mechanism (retaining screw) will not work for IQ modules. To remove a module from your controller or expansion unit: 1.
  • Page 16 3a. Slide the top of the protective cover into the upper grooves of the unit. 3b. Snap the cover into place by pushing the retaining screw knob. AUTION Failure to reinstall protective covers over empty slots will result in ventilation problems. IQS-2100...

  • Page 17: Starting The Light Source Application

    Getting Started with Your Light Source Starting the Light Source Application Starting the Light Source Application Your IQS-2100 Light Source module can be configured and controlled from its dedicated IQS Manager application. Note: For details about IQS Manager, refer to the IQS platform user guide.
  • Page 18 Note: To start the corresponding monitor window at the same time, click Start App. & Monitor. The window opens on the Monitors function tab. The main window (shown below) contains all the commands required to control the Light Source: Title bar Data display Function Control Center Status bar IQS-2100...
  • Page 19 Remote: Module controlled remotely, but local commands can also be used. Lockout: Module controlled remotely only. Module/unit status Current date and time For more information about automating or remotely controlling the IQS-2100 Light Source, refer to your platform user guide. Light Source...
  • Page 20 In addition to the Control Center, the main window also contains the data display, where the source status indicator, as well as values for wavelength, modulation, and attenuation controls are shown (see figure below). Signal wavelength Source status indicator Modulation value Attenuation value indicator indicator IQS-2100...

  • Page 21: Entering Values Using Sliders And Numeric Boxes

    Getting Started with Your Light Source Entering Values Using Sliders and Numeric Boxes Entering Values Using Sliders and Numeric Boxes Many parameters in IQS Manager and module applications can be set using the following tools. Slider Fine-tuning Numeric box button Navigation buttons Slider: Drag it to the desired value on the scale below.

  • Page 22: Exiting The Application

    To close the application from the main window: Click in the top right corner of the main window. Click the Exit button located at the bottom of the function bar. To close all currently running applications: From IQS Manager, click Close All Applications. IQS-2100...

  • Page 23: Setting Up Your Light Source

    Note: You do not need to turn on the IQS-2100 Light Source or connect it to a DUT to set it up. To turn on the source, see Operating Your Light Source on page 25.

  • Page 24: Selecting A Wavelength

    Setting Up Your Light Source Selecting a Wavelength Selecting a Wavelength If you are using a dual-wavelength module, you can select a wavelength to perform your tests. When the source is activated, the wavelength appears in the top right corner. IQS-2100...
  • Page 25 Setting Up Your Light Source Selecting a Wavelength To select the desired wavelength: Click the appropriate button in the Wavelength panel. A green light identifies the selected wavelength. To indicate a successful wavelength selection, the message Stabilization in progress... appears on the data display (only if the source is an active laser).

  • Page 26: Setting The Attenuation

    Setting Up Your Light Source Setting the Attenuation Setting the Attenuation You can modify the power of the IQS-2100 Light Source output by attenuating the emitted signal. With some IQS-2100 Light Source models, the Attenuation control is grayed out during the stabilization period, which occurs after you have selected a wavelength if the source is activated.
  • Page 27 Setting Up Your Light Source Setting the Attenuation The attenuation value in the data display will then indicate the increased or decreased attenuation. As you change the attenuation value, you will notice that the numbers change from green to orange. After you release the attenuation controls, they revert to their original green color to indicate that the change has been applied to the source (when it is active).

  • Page 28: Selecting A Modulation Frequency

    Setting Up Your Light Source Selecting a Modulation Frequency Selecting a Modulation Frequency You can modulate the laser output of the IQS-2100 Light Source to simulate data transfer. A number of modulation frequencies are available. To select a modulation frequency: 1.

  • Page 29: Saving And Recalling Configurations

    Setting Up Your Light Source Saving and Recalling Configurations Saving and Recalling Configurations Once you have set the IQS-2100 Light Source parameters, you can save your custom configuration and recall it at any time. You can also recall the factory-defined settings.
  • Page 30 To revert to factory settings: 1. Select the Configuration function tab. 2. Click the Reset Module to Factory Settings button. MPORTANT Reverting to the factory settings will interrupt any module operation in progress. MPORTANT The operation may take a few seconds to complete. IQS-2100...

  • Page 31: Operating Your Light Source

    To ensure maximum power and to avoid erroneous readings: Always clean fiber ends as explained below before inserting them into the port. EXFO is not responsible for damage or errors caused by bad fiber cleaning or handling. Ensure that your patchcord has appropriate connectors. Joining mismatched connectors will damage the ferrules.

  • Page 32: Installing The Exfo Universal Interface (Eui)

    Operating Your Light Source Installing the EXFO Universal Interface (EUI) If your connector features a screwsleeve, tighten the connector enough to firmly maintain the fiber in place. Do not overtighten, as this will damage the fiber and the port. Note: If your fiber-optic cable is not properly aligned and/or connected, you will notice heavy loss and reflection.

  • Page 33: Activating Or Deactivating Light Emission

    Operating Your Light Source Activating or Deactivating Light Emission Activating or Deactivating Light Emission Before activating the source, read carefully Safety Information on page 5. Upon source activation, the set parameter values are used. Therefore, make sure the source setup is correct before activation. Data display Red arrows Source...

  • Page 34: Viewing Results

    29. Viewing Results You cannot view results directly using the IQS-2100 Light Source software. To view results, you must use modules and systems which perform tests. For more information, refer to test modules or system user guides, or call EXFO.

  • Page 35: Monitoring Light Source Modules

    Monitoring Light Source Modules When using your IQS-2100 Light Source module, either alone or with other modules in a test setup, you can view module data and status using its monitor window in IQS Manager. Using Monitor Windows Monitor windows display basic data about modules. A combination of resizable windows allows you to create an integrated data display (refer to the platform user guide).
  • Page 36 3. Click Start Monitor to apply your selection. IQS Manager will display the selected monitor windows on the Monitors function tab. Note: To start the highlighted module’s corresponding application at the same time, click Start App. & Monitor. The application will appear in a different window. IQS-2100...
  • Page 37 Monitoring Light Source Modules Using Monitor Windows Remove Monitor button Rearrange Monitors button (1 or 2 columns) Close All Monitor window button arrow buttons Light Source...

  • Page 38: Using Quicktools

    2. Using the arrow button in the upper left corner, select QuickTools. The corresponding monitor window flashes when QuickTools is activated. Note: If you want to open the actual application for your module rather than QuickTools, click Show Controller. IQS-2100...
  • Page 39 Monitoring Light Source Modules Using QuickTools For the IQS-2100 Light Source, one of the two QuickTools utility versions will be displayed, depending on the selected module, as shown in the following figure. Single- Dual- wavelength wavelength source source QuickTools QuickTools...
  • Page 40 Click the Close button located at the top of the window. Click outside the QuickTools window. To close a monitor window: Click the button on the upper left of the monitor window and select Remove Monitor. Click the Close All button at the bottom of the window. IQS-2100...

  • Page 41: Maintenance

    Maintenance To help ensure long, trouble-free operation: Always clean fiber-optic connectors before using them. Keep the unit free of dust. Clean the unit casing and front panel with a cloth slightly dampened with water. Store unit at room temperature in a clean and dry area. Keep the unit out of direct sunlight.

  • Page 42: Cleaning Fixed Connectors

    4. With a dry lint-free wiping cloth, gently wipe the same surfaces three times with a rotating movement. 5. Throw out the wiping cloths after one use. 6. Moisten a cleaning tip (2.5 mm tip) with only one drop of isopropyl alcohol. IQS-2100...
  • Page 43 9. Continue to turn as you withdraw the cleaning tip. 10. Repeat steps 7 to 9, but this time with a dry cleaning tip (2.5 mm tip provided by EXFO). Note: Make sure you don’t touch the soft end of the cleaning tip and verify the cleanliness of the cotton tip.

  • Page 44: Cleaning Eui Connectors

    3. Slowly insert the cleaning tip into the EUI adapter until it comes out on the other side (a slow clockwise rotating movement may help). 4. Gently turn the cleaning tip one full turn, then continue to turn as you withdraw it. IQS-2100...
  • Page 45 6c. With a dry lint-free wiping cloth, gently wipe the same surfaces to ensure that the connector and ferrule are perfectly dry. 6d. Verify connector surface with a portable fiber-optic microscope (for example, EXFO’s FOMS) or inspection probe (for example, EXFO’s FIP). ARNING Verifying the surface of the connector WHILE THE UNIT IS ACTIVE WILL result in permanent eye damage.

  • Page 46: Recalibrating The Unit

    You should determine the adequate calibration interval for your unit according to your accuracy requirements. Under normal use, EXFO recommends calibrating your unit every year. IQS-2100...

  • Page 47: Recycling And Disposal (Applies To European Union Only)

    This equipment was sold after August 13, 2005 (as identified by the black rectangle). Unless otherwise noted in a separate agreement between EXFO and a customer, distributor or commercial partner, EXFO will cover costs related to the collection, treatment, recovery and disposal of...

  • Page 49: Troubleshooting

    Solving Common Problems The following is a list of common problems along with their possible causes and some recommended actions to solve them. Note: In all cases, if problem persists after performing the recommended actions, contact EXFO. Problem Possible Cause Recommended Action LED push button does not Power not on.

  • Page 50: Viewing Online Documentation

    Troubleshooting Viewing Online Documentation Viewing Online Documentation An online version of the IQS-2100 Light Source user guide is available at all times from the application. To access the online user guide: Click Help in the function bar. IQS-2100...

  • Page 51: Contacting The Technical Support Group

    Contacting the Technical Support Group To obtain after-sales service or technical support for this product, contact EXFO at one of the following numbers. The Technical Support Group is available to take your calls from Monday to Friday, 8:00 a.m. to 7:00 p.m.
  • Page 52 Select the Technical Support tab to view phone numbers and active Internet links to EXFO’s Technical Support Group. Use these links to send an information request by email or to access EXFO’s web site. Select the Module Information tab to view the module identification, serial number and firmware version.

  • Page 53: Transportation

    Troubleshooting Transportation Transportation Maintain a temperature range within specifications when transporting the unit. Transportation damage can occur from improper handling. The following steps are recommended to minimize the possibility of damage: Pack the unit in its original packing material when shipping. Avoid high humidity or large temperature fluctuations.

  • Page 55: Warranty

    SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES. Liability EXFO shall not be liable for damages resulting from the use of the product, nor shall be responsible for any failure in the performance of other items to which the product is connected or the operation of any system of which the product may be a part.

  • Page 56: Exclusions

    Warranty Exclusions Exclusions EXFO reserves the right to make changes in the design or construction of any of its products at any time without incurring obligation to make any changes whatsoever on units purchased. Accessories, including but not limited to fuses, pilot lamps, batteries and universal interfaces (EUI) used with EXFO products are not covered by this warranty.

  • Page 57: Service And Repairs

    5. Return the equipment, prepaid, to the address given to you by support personnel. Be sure to write the RMA number on the shipping slip. EXFO will refuse and return any package that does not bear an RMAnumber.

  • Page 58: Exfo Service Centers Worldwide

    Warranty EXFO Service Centers Worldwide EXFO Service Centers Worldwide If your product requires servicing, contact your nearest authorized service center. EXFO Headquarters Service Center 400 Godin Avenue 1 866 683-0155 (USA and Canada) Quebec (Quebec) G1M 2K2 Tel.: 1 418 683-5498...

  • Page 59: A Technical Specifications

    The following technical specifications can change without notice. The information presented in this section is provided as a reference only. To obtain this product’s most recent technical specifications, visit the EXFO Web site at www.exfo.com. SPECIFICATIONS TEC Fabry-Perot Laser Specifications...

  • Page 61: Bscpi Command Reference

    SCPI Command Reference This appendix presents detailed information on the commands and queries supplied with your IQS-2100 Light Source. MPORTANT Since the IQS controllers and expansion units can house many instruments, you must explicitly specify which instrument you want to remotely control.

  • Page 62: Quick Reference Command Tree

    SCPI Command Reference Quick Reference Command Tree Quick Reference Command Tree Command Parameter(s) SNUMber? SOURce[1..n] INTernal FREQuency <ModulationFreq[<wsp>HZ]> FREQuency? POWer ATTenuation <Attenuation[<wsp>DB]>|MAXim um|MINimum|DEFault ATTenuation? [MAXimum|MINimum|DEFault] STATe <PowerState> STATe? WAVelength UPPer|LOWer WAVelength? WAVelength COUNt? LOWer? UPPer? STATus? IQS-2100...

  • Page 63: Product-Specific Commands-Description

    SCPI Command Reference Product-Specific Commands—Description Product-Specific Commands—Description :SNUMber? Description This query returns a value indicating the serial number of the module. Syntax :SNUMber? Parameter(s) None Response Syntax <SerialNumber> Response(s) SerialNumber: The response data syntax for <SerialNumber> is defined as a <STRING RESPONSE DATA> element.
  • Page 64 DATA> element followed by an optional <SUFFIX PROGRAM DATA> element. The allowed <SUFFIX PROGRAM DATA> element is The <ModulationFreq> parameter is the new modulation frequency: 270, 1000, 2000, or 0 (CW). Example(s) SOUR:POW:STAT ON SOUR:AM:INT:FREQ 2000Hz See Also SOURce[1..n]:AM:INTernal:FREQuency? IQS-2100...
  • Page 65 SCPI Command Reference Product-Specific Commands—Description :SOURce[1..n]:AM:INTernal: FREQuency? Description This query returns a value indicating the current internal modulation frequency. If the source is in CW mode, the function will return 0. *RST sets the modulation frequency to 0 Hz (CW). Syntax :SOURce[1..n]:AM:INTernal:FREQuency? Parameter(s)
  • Page 66 MAXimum allows to set the instrument to the greatest supported value. DEFault allows the instrument to select a value for the <Attenuation> parameter. The <Attenuation> parameter is the new power attenuation in dB. The power attenuation is always a positive value. IQS-2100...
  • Page 67 SCPI Command Reference Product-Specific Commands—Description :SOURce[1..n]:POWer:ATTenuation Example(s) SOUR:POW:STAT ON SOUR:POW:ATT 2 Notes Instrument must be in the Ready state to execute this command. See Also SOURce[1..n]:POWer:ATTenuation? Light Source...
  • Page 68 DATA> elements for this parameter are: MAXimum|MINimum|DEFault. MINimum is used to retrieve the instrument's smallest supported value. MAXimum is used to retrieve the instrument's greatest supported value. DEFault is used to retrieve the instrument's default value. Response Syntax <Attenuation> IQS-2100...
  • Page 69 SCPI Command Reference Product-Specific Commands—Description :SOURce[1..n]:POWer:ATTenuation? Response(s) Attenuation: The response data syntax for <Attenuation> is defined as a <NR3 NUMERIC RESPONSE DATA> element. The <Attenuation> response is the power attenuation of the source, in dB. Example(s) SOUR:POW:STAT ON SOUR:POW:ATT 3 SOUR:POW:ATT? See Also SOURce[1..n]:POWer:ATTenuation...
  • Page 70 ON corresponds to 1 and OFF corresponds to 0. The <PowerState> parameter is the new power state of the source. Example(s) SOUR:POW:STAT ON Notes Instrument must be in the Ready state to execute this command. See Also SOURce[1..n]:POWer:STATe? IQS-2100...
  • Page 71 SCPI Command Reference Product-Specific Commands—Description :SOURce[1..n]:POWer:STATe? Description This query returns a value indicating the state of the optical source (on or off). *RST sets the optical source to OFF. Syntax :SOURce[1..n]:POWer:STATe? Parameter(s) None Response Syntax <PowerState> Response(s) PowerState: The response data syntax for <PowerState> is defined as a <NR1 NUMERIC RESPONSE DATA>...
  • Page 72 LOWer, switches to the lowest wavelength. Example(s) SOUR:POW:WAV LOW Wait 3 seconds. SOUR:POW:STAT ON Notes Instrument must be in the Ready state to execute this command. This command can cause the instrument to enter the Stabilizing state. See Also SOURce[1..n]:POWer:WAVelength? SOURce[1..n]:POWer:WAVelength:LOWer? SOURce[1..n]:POWer:WAVelength:UPPer? IQS-2100...
  • Page 73 SCPI Command Reference Product-Specific Commands—Description :SOURce[1..n]:POWer:WAVelength? Description This query returns a value indicating which wavelength is currently selected. *RST sets the selected wavelength to the LOW value. Syntax :SOURce[1..n]:POWer:WAVelength? Parameter(s) None Response Syntax <SelectedSources> Response(s) SelectedSources: The response data syntax for <SelectedSources>...
  • Page 74 Response(s) NbWavelength: The response data syntax for <NbWavelength> is defined as a <NR1 NUMERIC RESPONSE DATA> element. The <NbWavelength> response is the number of wavelengths available on the instrument: 1, one wavelength available 2, two wavelengths available Example(s) SOUR:POW:WAV:COUN? IQS-2100...
  • Page 75 SCPI Command Reference Product-Specific Commands—Description :SOURce[1..n]:POWer:WAVelength: LOWer? Description This query returns a value indicating the lower wavelength. *RST has no effect on this command. Syntax :SOURce[1..n]:POWer:WAVelength:LOWer? Parameter(s) None Response Syntax <LowerWavelength> Response(s) LowerWavelength: The response data syntax for <LowerWavelength> is defined as a <NR3 NUMERIC RESPONSE DATA>...
  • Page 76 The response data syntax for <UpperWavelength> is defined as a <NR3 NUMERIC RESPONSE DATA> element. The <UpperWavelength> response is the highest source wavelength value in meters. Example(s) SOUR:POW:WAV:UPP? Notes Not available on single-source instruments. See Also SOURce[1..n]:POWer:WAVelength SOURce[1..n]:POWer:WAVelength? SOURce[1..n]:POWer:WAVelength:LOWer? IQS-2100...
  • Page 77 SCPI Command Reference Product-Specific Commands—Description :STATus? Description This query returns a value indicating the status of the module (READY, BUSY, etc.). Syntax Parameter(s) None Response Syntax Response(s) Status: Example(s) STAT? Returns READY (Module is ready.) Light Source...
