Hardware Installation and Reference Guide
1

Product Introduction

RG-AP820(AR) is an IEEE 802.11ax-compliant AR series wireless access point (AP) released by Ruijie
Networks for indoor high-density scenarios in the higher education, government, general education, finance,
and business sectors.
The RG-AP820(AR) complies with the IEEE 802.11ax, 802.11ac Wave 2, 802.11ac Wave 1, and 802.11n
protocols. It adopts the tri-radio design and can provide a maximum wireless access rate of 3.267 Gbps, which
breaks through the bottleneck in wireless performance.
The RG-AP820(AR) integrates Ruijie's exclusive AI Radio design. The extra intelligent radio card provides better
access experience and real-time full-band security protection for users in the Wi-Fi 6 environment.
Important factors such as the wireless network security, radio control, mobile access, Quality of Service (QoS),
seamless roaming, and expansion of the Internet of Things (IoT) module are fully taken into account for the RG-
AP820(AR). Therefore, this AP can be used together with Ruijie's access controllers (ACs) and WIS to
implement STA data forwarding, security, access control, and IoT application extension.
Moreover, the RG-AP820(AR) supports local power supply and power over Ethernet (PoE), which can be
selected based on power supply conditions. In addition, this AP can be mounted onto a wall or ceiling, making
the AP especially applicable to large campuses, conference centers, plazas, or other densely populated
scenarios.
1.1 RG-AP820(AR)
Specifications
Hardware Specifications
RF Design
Transmission
Protocol
Operating Bands
Spatial Streams
Transmission
Rate
Tri-radio design:
Radio 1: 2.4 GHz/5 GHz, 2 × 2 MIMO
Radio 2: 5 GHz, 2 × 2 MIMO
Radio 3: 2.4 GHz/5 GHz, 2 × 2 MIMO
Standard IEEE 802.11ax protocol and tri-radio dual-band design, which allows
the AP to work in IEEE 802.11ax and IEEE 802.11a/b/g/n/ac modes
simultaneously
IEEE 802.11b/g/n/ax: 2.4 GHz to 2.483 GHz
IEEE 802.11a/n/ac/ax: 5.150 GHz to 5.350 GHz, 5.47 GHz to 5.725 GHz, and
5.725 GHz to 5.820 GHz (Note: The operating band varies in different countries.)
Six spatial streams per device
Maximum access rate of the AP: 3.267 Gbps
Radio 1: 2.4 GHz, 0.575 Gbps/5 GHz L, 1.2 Gbps
